CURRENT CPU TEMPERATURE:
This item shows you the current CPU temperature.
CURRENT SYSTEM FAN SPEED:
This item shows you the current System FAN speed.
CURRENT CPU FAN SPEED:
This item shows you the current CPUFAN speed.
VCORE:
This item shows you the current system voltage.
3.3V / +5V / +12V / -12V / -5V / 5VSB:
Show you the voltage of 3.3V/+5V/+12V/-12V/-5V/5VSB.
SHUTDOWN TEMPERATURE:
This item allows you to set up the CPU shutdown Temperature.
This function is only effective under Windows 98 ACPI mode.
79
Award BIOS Setup
