JUMPER DIAGRAMS
JUMPER SETTINGS
1
1
1 2
Hardware Configuration
®
SBC81870 Intel
Pentium
Jumper Cap
looks like this
2 pin Jumper
looks like this
3 pin Jumper
looks like this
Jumper Block
looks like this
2 pin Jumper close(enabled)
Looks like this
3 pin Jumper
2-3 pin close(enabled)
Looks like this
Jumper Block
1-2 pin close(enabled)
Looks like this
®
M w/ DDR/VGA/Dual LAN
1
1
1 2
13
