  • Page 1 SBC84833 Series ® Intel Atom™ Processor N270 Capa Board with LVDS User’s Manual...
  • Page 2 Axiomtek does not make any commitment to update the information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval...

  • Page 3: Esd Precautions

    Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd. ® Windows is a trademark of Microsoft Corporation. ®...

  • Page 4: Table Of Contents

    Table of Contents   Disclaimers ................. II   ESD Precautions ................ III CHAPTER 1 ....................1   INTRODUCTION ..................1       Specifications ............2     Utilities Supported ............ 4 CHAPTER 2 ....................5   JUMPERS AND CONNECTORS ............5  ...
  • Page 5     2.4.13 Serial Port 2 Connectors (CN15) ....30     2.4.14 Power output Connector (CN8) ....31     2.4.15 Ethernet Connectors (LAN1) ......31     2.4.16 SATA Connectors (SATA1, SATA2) ..... 31     2.4.17 USB Port Connector (USB3) ....... 32  ...

  • Page 7: Chapter 1

    SBC84833 Series All-In-One Capa Board User’s Manual CHAPTER 1 INTRODUCTION ® ™ The SBC84833, a Capa board, supports Intel Atom processor ® N270, at FSB 533 MHz. The board integrates chipsets Intel 945GSE and ICH7M that deliver outstanding system performance through high- bandwidth interfaces, multiple I/O functions for interactive applications and various embedded computing solutions.

  • Page 8: Specifications

    SBC84833 Series All-In-One Capa Board User’s Manual Specifications ® Intel Atom processor N270 System Chipset ® Intel 945GSE & ICH7M Front-Side Bus 533 MHz BIOS American Megatrends Inc. BIOS. 8Mbit SPI Flash, DMI, Plug and Play “Load Optimized Default” to backup customized Setting in...
  • Page 9 SBC84833 Series All-In-One Capa Board User’s Manual Onboard Multi I/O Controller: Winbond W83627UHG Serial Ports: One port for RS-232/422/485 and three ports for RS-232 Two SATA-150 connectors ™ CompactFlash Socket One CompactFlash™ Type II Socket USB Interface Seven USB ports with fuse protection and complies with USB Spec.

  • Page 10: Utilities Supported

    SBC84833 Series All-In-One Capa Board User’s Manual Utilities Supported Chipset Driver Ethernet Driver Graphic Driver Audio Driver INTRODUCTION...

  • Page 11: Chapter 2

    SBC84833 Series All-In-One Capa Board User’s Manual CHAPTER 2 JUMPERS AND CONNECTORS Board Dimensions and Fixing Holes Component Side JUMPERS AND CONNECTORS...
  • Page 12 SBC84833 Series All-In-One Capa Board User’s Manual Solder Side JUMPERS AND CONNECTORS...

  • Page 13: Board Layout

    SBC84833 Series All-In-One Capa Board User’s Manual Board Layout Component Side JUMPERS AND CONNECTORS...
  • Page 14 SBC84833 Series All-In-One Capa Board User’s Manual Solder Side JUMPERS AND CONNECTORS...

  • Page 15: Jumper Settings

    SBC84833 Series All-In-One Capa Board User’s Manual Jumper Settings Proper jumer settings configure the SBC84833 to meet your application purpose. We are herewith listing a summary table of all jumpers and default settings for onboard devices, respectively. Jumper Default Setting...

  • Page 16: Lcd Voltage Slection Jumper (Jp1)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.1 LCD Voltage Slection Jumper (JP1) The board supports +3.3V or +5V flat panel displays. Configure the jumper JP1 to the appropriate voltage of the flat panel. Description Function Jumper Setting LCD Voltage 3.3V...

  • Page 17: Compactflash™ Voltage Jumper (Jp3)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.3 CompactFlash™ Voltage Jumper (JP3) ™ The jumper is to select the voltage for CompactFlash interface. Description Function Jumper Setting Compact Flash 3.3V Voltage (Default) Selection JUMPERS AND CONNECTORS...

  • Page 18: Cmos Clear Jumper (Jp4)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.4 CMOS Clear Jumper (JP4) You may need to use this jumper is to clear the CMOS memory if incorrect settings in the Setup Utility. Description Function Jumper Setting CMOS Clear Normal (Default)

  • Page 19: Auto Power On Jumper (Jp5)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.5 Auto Power On Jumper (JP5) When Jumper JP5 is set OPEN for AC power input, the system will be automatically power ON without pressing soft power button; when JP5 is SHORT for AC power input, it is necessary to manually press soft power button to make the system power ON.

  • Page 20: Com1 Mode Select Jumpers (Jp6, Jp7, Jp8)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.6 COM1 Mode Select Jumpers (JP6, JP7, JP8) These jumpers select the communication mode of COM1 port to operate RS-232 or RS-422 or RS-485. Description Function Jumper Setting RS-232 (Default) COM 1 RS-422...

  • Page 21: Com2 Mode Selection Jumper (Jp9)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.7 COM2 Mode Selection Jumper (JP9) The jumper selects the DCD and RI mode of CN15 COM2 port. Description Function Jumper Setting COM2 CN15 Pin 1=5V CN15 Pin 1=DCD (Default) CN15 Pin 8=12V...

  • Page 22: Com1 Mode Selection Jumper (Jp10)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.8 COM1 Mode Selection Jumper (JP10) The jumper selects the DCD and RI mode of COM1 port. Description Function Jumper Setting COM1 Pin 1=5V Pin 1=DCD (Default) Pin 8=12V Pin 8=RI (Default) JUMPERS AND CONNECTORS...

  • Page 23: Com3 Mode Selection Jumper (Jp11)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.9 COM3 Mode Selection Jumper (JP11) The jumper selects the DCD and RI mode of CN10 COM3 port. Description Function Jumper Setting COM3 CN10 Pin 1=5V CN10 Pin 1=DCD (Default) CN10 Pin 8=12V...

  • Page 24: Com4 Mode Selection Jumper (Jp12)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.10 COM4 Mode Selection Jumper (JP12) The jumper selects the DCD and RI mode of CN10 COM4 port. Description Function Jumper Setting COM4 CN10 Pin 11=5V CN10 Pin 11=DCD (Default) CN10 Pin 18=12V...

  • Page 25: Crt Always On Jumper (Jp13)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.3.11 CRT Always On Jumper (JP13) When Jumper is set Enable, the screen is always output by CRT. Description Function Jumper Setting CRT Always Disable Enable (Default) JUMPERS AND CONNECTORS...

  • Page 26: Connectors

    Connectors connect the board with other parts of the system. Loose or improper connection might cause problems. Make sure all connectors are properly and firmly connected. Here is a summary table which shows you all connectors on the SBC84833 Series. Connectors Label...

  • Page 27: Atx 4 Pin 12V Connector (Atx1)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.1 ATX 4 Pin 12V Connector (ATX1) Connect it to the power supply ATX12V power. Signal +12V +12V 2.4.2 LVDS Backlight Connector (CN1) The CN1 is DF13-7S-1.25C 7-pin connectors for inverter, We strongly recommend you to use the matching DF13-7S-1.25C connector.

  • Page 28: Lvds Flat Panel Connector (Cn3)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.4 LVDS Flat Panel Connector (CN3) The board has a 40-pin connector CN3 for LVDS Interface LCD. It is strongly recommended to use the matching GLA1001WV-S-2x20P 40- pin connector for LVDS on the board.

  • Page 29: Flat Panel Bezel Connector (Cn4)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.5 Flat Panel Bezel Connector (CN4) Power LED Pin 1 and Pin 5 connect the system power LED indicator with the corresponding switch on the case. Pin 1 is assigned as +, and Pin 3 &...
  • Page 30 SBC84833 Series All-In-One Capa Board User’s Manual ATX Power On/Off Button Pin 9 and 10 connect the ATX power button on front panel to the CPU card, which allows users to control ATX power supply to be power on/off. System Reset Switch Pin 11 and 12 connect the case-mounted reset switch that reboots your computer without turning OFF the power switch.

  • Page 31: Digital I/O Port Connector (Cn6)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.6 Digital I/O Port Connector (CN6) The board is equipped with a 8-channel (3in, 5out) digital I/O connector that meets requirements for a system customary automation control. The digital I/O can be configured to control cash drawers and sense warning signals from an Uninterrupted Power System (UPS), or perform store security control.
  • Page 32 SBC84833 Series All-In-One Capa Board User’s Manual Signal Signal WAKE# +3.3V +1.5V CLK- CLK+ PERST# PERN3 +3.3VSB PERP3 +1.5V SMB_CLK PETN3 SMB_DATA PETP3 USB_D7- USB_D7+ +1.5V +3.3V JUMPERS AND CONNECTORS...

  • Page 33: Smbus Connector (Cn9)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.8 SMBus Connector (CN9) Connector CN9 is for SMBUS interface support. Signal CLOCK DATA JUMPERS AND CONNECTORS...

  • Page 34: Serial Port3 & Serial Port4 (Cn10)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.9 Serial Port3 & Serial Port4 (CN10) Signal Signal DCD3 DSR3 RXD3 RTS3 TXD3 CTS3 DTR3 N.C. DCD4 DSR4 RXD4 RTS4 TXD4 CTS4 DTR4 N.C. JUMPERS AND CONNECTORS...

  • Page 35: Keyboard And Ps/2 Mouse Connector (Cn11)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.10 Keyboard and PS/2 Mouse Connector (CN11) The board supports a PS/2 Keyboard and Mouse interface. Connector is a DIN connector for PS/2 keyboard Connection via “Y” Cable. Signal Keyboard Data Mouse Data...

  • Page 36: Serial Port1 Connector (Com1)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.12 Serial Port1 Connector (COM1) The COM 1 Port connector is a standard DB-9 connector. Signal DCD, Data carrier detect RXD, Receive data TXD, Transmit data COM1 DTR, Data terminal ready GND, ground...

  • Page 37: Power Output Connector (Cn8)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.14 Power output Connector (CN8) The CN8 can be the power supply for SATA 2.5" HD only. Signal +12V 2.4.15 Ethernet Connectors (LAN1) The RJ-45 connector is for Ethernet. To connect the board to a 1000/100/10 Base-T hub, just plug one end of the cable into connector and connect the other end (phone jack) to a 1000/100/10-Base-T hub.

  • Page 38: Usb Port Connector (Usb3)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.17 USB Port Connector (USB3) Signal Signal USB VCC0 USB VCC0 (+5VS) (+5VS) USB D0- USB D1- USB D0+ USB D1+ Ground (GND) Ground (GND) 2.4.18 Internal USB Connector (USB1) These Universal Serial Bus (USB) connectors on this board are for installing versatile USB interface peripherals.

  • Page 39: Internal Usb Connector (Usb4)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.19 Internal USB Connector (USB4) These Universal Serial Bus (USB) connectors on this board are for installing versatile USB interface peripherals. This is a 10- pin standard USB connector. Signal Signal USB VCC2...

  • Page 40: Compactflash™ Socket (Scf1)

    SBC84833 Series All-In-One Capa Board User’s Manual 2.4.21 CompactFlash™ Socket (SCF1) The board is equipped with a CompactFlash disk type-II socket on the solder side to support an IDE interface CompactFlash disk card with DMA mode supported. The socket is especially designed to avoid incorrect installation of the CompactFlash disk card.
  • Page 41 SBC84833 Series All-In-One Capa Board User’s Manual JUMPERS AND CONNECTORS...

  • Page 42: Chapter 3

    Make sure all correct settings are arranged for your installed microprocessor to prevent the CPU from damages. BIOS The SBC84833 Series uses AMI Plug and Play BIOS with a single 8Mbit SPI Flash, DMI, Plug and Play. System Memory...

  • Page 43: I/O Port Address Map

    SBC84833 Series All-In-One Capa Board User’s Manual I/O Port Address Map There are total 1KB port addresses (under OS WinXP) available for assignment to other devices via I/O expansion cards. HARDWARE DESCRIPTION...
  • Page 44 SBC84833 Series All-In-One Capa Board User’s Manual HARDWARE DESCRIPTION...

  • Page 45: Interrupt Controller

    SBC84833 Series All-In-One Capa Board User’s Manual Interrupt Controller The SBC84833 Series is a 100% PC compatible control board. It consists of 16 interrupt request lines, and four out of them can be programmable. The mapping list of the 16 interrupt request lines is shown as the following table.

  • Page 46: Chapter 4

    SBC84833 Series All-In-One Capa Board User’s Manual CHAPTER 4 AMI BIOS SETUP UTILITY This chapter provides users with detailed description about how to set up basic system configuration through the AMIBIOS8 BIOS setup utility. Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...
  • Page 47 SBC84833 Series All-In-One Capa Board User’s Manual The Left and Right <Arrow> keys allow you to select a Left/Right setup screen. The Up and Down <Arrow> keys allow you to select a Up/Down setup screen or sub-screen. The Plus and Minus <Arrow> keys allow you to +−...

  • Page 48: Main Menu

    SBC84833 Series All-In-One Capa Board User’s Manual Main Menu When you first enter the Setup Utility, you will enter the Main setup screen. You can always return to the Main setup screen by selecting the Main tab. There are two Main Setup options. They are described in this section.

  • Page 49: Advanced Menu

    SBC84833 Series All-In-One Capa Board User’s Manual Advanced Menu The Advanced menu allows users to set configuration of the CPU and other system devices. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 50 SBC84833 Series All-In-One Capa Board User’s Manual Configure advanced CPU settings This screen shows the CPU Configuration, and you can change the value of the selected option. Execute-Disable Bit Capability This item helps you enable or disable the No-Execution Page Protection Technology.
  • Page 51 SBC84833 Series All-In-One Capa Board User’s Manual Intel (R) C-STATE tech Use this item to enable or disable the C-State technology. Enhanced C-States this item to enable or disable any available enhanced C-states ( C1E, C2E, C3E, C4E and Hard C4E).
  • Page 52 SBC84833 Series All-In-One Capa Board User’s Manual Primary/Secondary/Third IDE Master/Slave Select one of the hard disk drives to configure IDE devices installed in the system by pressing <Enter> for more options. SuperIO Configuration Use this screen to select options for the SuperIO Configuration, and change the value of the selected option.
  • Page 53 SBC84833 Series All-In-One Capa Board User’s Manual Serial Port1 Address This item specifies the base I/O port address and Interrupt Request address of serial port 1. The Optimal setting is 3F8/IRQ4. The Fail- Safe default setting is Disabled. Serial Port1 IRQ This item specifies the IRQ used by the serial port 1.
  • Page 54 SBC84833 Series All-In-One Capa Board User’s Manual Hardware Health Configuration This screen shows the Hardware Health Configuration, and a description of the selected item appears on the right side of the screen. System Temperature/CPU Temperature These items display the temperature of CPU and System, Vcore, etc.
  • Page 55 SBC84833 Series All-In-One Capa Board User’s Manual ACPI Settings Use this screen to select options for the ACPI Settings, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 56 SBC84833 Series All-In-One Capa Board User’s Manual General ACPI Configuration Scroll this item and press <Enter> to view the General ACPI Configuration sub menu, which contains General ACPI (Advanced Configuration and Power Management Interface) options for your configuration. AMI BIOS SETUP UTILITY...
  • Page 57 SBC84833 Series All-In-One Capa Board User’s Manual Advanced ACPI Configuration Scroll this item and press <Enter> to view the Advanced ACPI Configuration sub menu, which contains Advanced ACPI (Advanced Configuration and Power Management Interface) options for your configuration. AMI BIOS SETUP UTILITY...
  • Page 58 SBC84833 Series All-In-One Capa Board User’s Manual Chipset ACPI Configuration Scroll to this item and press <Enter> to view the Chipset ACPI Configuration sub menu, which contains Chipset ACPI (Advanced Configuration and Power Management Interface) options for your configuration. AMI BIOS SETUP UTILITY...
  • Page 59 SBC84833 Series All-In-One Capa Board User’s Manual APM Configuration Use this screen to select options for the APM Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 60 SBC84833 Series All-In-One Capa Board User’s Manual Video Power Down Mode This option specifies the Power State. When the BIOS places it in a power saving state, the video subsystem enters when the BIOS places it in a power saving state after the specified period of display inactivity has expired.
  • Page 61 SBC84833 Series All-In-One Capa Board User’s Manual Power Button Mode This option specifies how the externally mounted power button on the front of the computer chassis is used. The default setting is On/Off. Pushing the power button turns the computer On/Off on or off.
  • Page 62 SBC84833 Series All-In-One Capa Board User’s Manual MPS Configuration This screen shows the MPS (Multi Processor Specification) Configuration, and you can change its value. A description of the selected item appears on the right side of the screen. MPS Revision Use this item to select MPS (Multi Processor Specification) Revision 1.1 or 1.4.
  • Page 63 SBC84833 Series All-In-One Capa Board User’s Manual USB Configuration You can use this screen to select options for the USB Configuration, and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 64 SBC84833 Series All-In-One Capa Board User’s Manual BIOS EHCI Hand-Off Enabling this item provides the support for operating systems without an EHCI hand-off feature.The default setting is Enabled. USB Mass Storage Device Configuration Scroll this item and press <Enter> to view the USB Mass Storage Device Configuration sub menu, which contains several options for your configuration.

  • Page 65: Boot Menu

    SBC84833 Series All-In-One Capa Board User’s Manual Boot Menu The Boot menu allows users to change boot options of the system. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 66 SBC84833 Series All-In-One Capa Board User’s Manual Boot Settings Configuration Quick Boot Enabling this item lets the BIOS skip some power on self tests (POST). The default setting is Enabled. AddOn ROM Display Mode This item selects the display mode for option ROM. The default setting is Force BIOS.
  • Page 67 SBC84833 Series All-In-One Capa Board User’s Manual PS/2 Mouse Support This item determines if the BIOS should reserve IRQ12 for the PS/2 mouse or allow other devices to make use of this IRQ. Here are the options for your selection, Auto, Enabled and Disabled.

  • Page 68: Security Menu

    SBC84833 Series All-In-One Capa Board User’s Manual Security Menu The Security menu allows users to change the security settings for the system. Supervisor Password This item indicates whether a supervisor password has been set. If the password has been installed, Installed displays. If not, Not Installed displays.

  • Page 69: Chipset Menu

    SBC84833 Series All-In-One Capa Board User’s Manual Chipset Menu The Chipset menu allows users to change the advanced chipset settings. You can select any of the items in the left frame of the screen to go to the sub menus:...
  • Page 70 SBC84833 Series All-In-One Capa Board User’s Manual North Bridge Configuration DRAM Frequency Use this item to control the Memory Clock. Configure DRAM Timing by SPD Use this item to enable or disable DRAM timing by SPD (Serial Presence Detect) device, which is a small EEPROM chip on the memory module, containing important information about the module speed, size, addressing mode and various parameters.
  • Page 71 SBC84833 Series All-In-One Capa Board User’s Manual Boot Graphic Adapter Priority This item allows you to select the graphics controller as the primary boot device. Internal Graphics Mode Select This item allows you to select the amount of system memory used by the internal graphics device.
  • Page 72 SBC84833 Series All-In-One Capa Board User’s Manual South Bridge Configuration Restore on AC Power Loss This item can control how the PC will behave once power is restored following a power outage, or other unexpected shutdown. PCIE Port Configuration This item allows you to set or disable the PCI Express Ports.

  • Page 73: Exit Menu

    SBC84833 Series All-In-One Capa Board User’s Manual Exit Menu The Exit menu allows users to load the system configuration with optimal or failsafe default values. AMI BIOS SETUP UTILITY...
  • Page 74 SBC84833 Series All-In-One Capa Board User’s Manual Save Changes and Exit When you have completed the system configuration changes, select this option to leave Setup and reboot the computer so the new system configuration parameters can take effect. Select Save Changes and Exit from the Exit menu and press <Enter>.

  • Page 75: Appendix A

    SBC84833 Series All-In-One Capa Board User’s Manual APPENDIX A WATCHDOG TIMER What is Watchdog Timer The integrated Watchdog Timer can be set up by programming. There are 1~255 levels available. As long as the vaule of timer is set, after enabling, the countdown of the value is starting. It needs to reset or disable watchdog, otherwise auto-reset will be running when the value is counted to 0.
  • Page 76 SBC84833 Series All-In-One Capa Board User’s Manual al,Nh ;N=00h or 08h(See below Note) dx,al ;Set base timer : dx,2Eh al,0F6h dx,al dx,2Fh al,Mh ;M=00h,01h,02h,..FFh (Hex),Value=0 to 255 dx,al ; (See below Note) ;Disable WDT: dx,2Eh al,30h dx,al dx,2Fh al,00h ;Can be disable at ant time...
  • Page 77 SBC84833 Series All-In-One Capa Board User’s Manual When program A has problems to make system shut down, the system can be rebooted by Watchdog timer when the value of watchdog timer is countdowned to 0. The below flowchart can be referred to edit program A.

  • Page 78: Appendix B

    SBC84833 Series All-In-One Capa Board User’s Manual APPENDIX B DIGITAL I/O Signal Signal Digital Input 0 Digital Output 0 (Bit0) (Bit3) Digital Input 1 Digital Output 1 (Bit1) (Bit4) Digital Input 2 Digital Output 2 (Bit2) (Bit5) Digital Output 3...

  • Page 79: Digital I/O Software Programming

    SBC84833 Series All-In-One Capa Board User’s Manual Digital I/O has 8bits (DIO0~7). Every bit can be programmed input or output and is set pull-high with +5V level (main power)as default. BIOS default is 3 IN 5 OUT. The default set all of input and output pin to “1”.
  • Page 80 SBC84833 Series All-In-One Capa Board User’s Manual dx, al ;Bit0 ~ Bit2 are DIO0~2 state. (1 High, 0 Low, Note2) Digital Output ; Set DIO digital output pins’ value. dx,2Eh al,0E1h dx,al dx,2Fh al,M ;If N’s value is 07h, Bit3 ~ Bit7 represent DIO3 ~ DIO7, dx,al ;Set output value M...
  • Page 81 SBC84833 Series All-In-One Capa Board User’s Manual When DIO0~2 connect external device. The device sets DIO0~2 are high. DIO7 DIO6 DIO5 DIO4 DIO3 DIO2 DIO1 DIO0 When DIO0~2 connect external device. The device sets DIO0 is low and DIO1~2 are high.
