  • Page 1 SBC86620 Series GX3 All-in-One Mini ITX Board User’s Manual...
  • Page 2 AXIOMTEK does not warrant or assume any legal liability or responsibility for the accuracy, completeness or usefulness of any information in this document. AXIOMTEK does not make any commitment to update the information in this manual.

  • Page 3: Esd Precautions

    Wear a wrist-grounding strap, available from most electronic component stores, when handling boards and components. Trademarks Acknowledgments AXIOMTEK is a trademark of AXIOMTEK Co., Ltd. ® MS-DOS and Windows ’95 are trademarks of Microsoft Corporation.

  • Page 4: Table Of Contents

    Table of Content Disclaimers ........................ ii ESD Precautions ...................... iii Chapter 1 Introduction ................ 1 Specifications ....................2 Utilities Supported ..................3 Chapter 2 Jumpers and Connectors ..........5 Board Dimensions and Fixing Holes ............5 Board Layout ....................8 Jumper Settings ...................
  • Page 5 2.4.23 LVDS Flat Panel Connector: CN23_LVDS1........27 2.4.24 VGA Connector: VGA1................ 28 2.4.25 Floppy Disk Connector: FDD1............28 2.4.26 Parallel Port: LPT1 ................29 2.4.27 PICMG compliant PCI Connector: PL1 ..........29 2.4.28 USB (Disk On Module) Connector: USB1 .......... 31 Chapter 3 Hardware Description............
  • Page 6 MEMO...

  • Page 7: Chapter 1 Introduction

    232/422/485) with +5V/12V power Mini ITXbility and that allow adoption of an extensive array of PC peripherals. The industrial-grade construction of SBC86620 series allows your system to endure the continuous operation in hostile environments where stability and reliability are basic requirements. System dependability of SBC86620 series are enhanced by its built-in watchdog timer, a special industrial feature not commonly seen on other motherboards.

  • Page 8: Specifications

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Specifications CPU: AMD LX800(GX3) CPU ;LX700 is optional System Chipset: CS5536AD CPU Frequency: 500MHz/433MHZ(LX700) BIOS: Phoenix-Award BIOS, Y2K compliant 4Mbit Flash, DMI, Plug and Play SmartView for multiple LCD type selection, display mode option and application extension features RPL/PXE Ethernet Boot ROM “Load Optimized Default”...

  • Page 9: Utilities Supported

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Unified Memory Architecture shares system memory up to 254MB LCD Interface:Support up to 24/18-bit LVDS Single display mode maximum resolutions: CRT: 1920 x 1440 LVDS: 1600 x 1200 Ethernet: Dual Realtek RTL8100C PCI Bus 10/100M Base-T Wake On LAN (via ATX power supply) Equipped with RJ-45 interface Audio:...
  • Page 10 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual MEMO Introduction...

  • Page 11: Chapter 2 Jumpers And Connectors

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual C h a p t e r 2 Jumpers and Connectors Board Dimensions and Fixing Holes Jumpers and Connectors...
  • Page 12 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Jumpers and Connectors...
  • Page 13 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Jumpers and Connectors...

  • Page 14: Board Layout

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Board Layout The Limited Height of Component side is 30mm. Jumpers and Connectors...

  • Page 15: Jumper Settings

    Geode GX3 Mini ITX Board User’s Manual Jumper Settings The SBC86620 Series is configured to match the needs of your application with the proper jumper settings. The table below is a summary of all the jumpers and their corresponding functions onboard the SBC86620 Series.

  • Page 16: Cmos Clear Jumper: Jp1

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.3.1 CMOS Clear Jumper: JP1 Options Settings Short 1-2 (default) Normal Short 2-3 Clear CMOS 2.3.2 Compact Flash Voltage Selection: JP2 Options Settings Short 1-2 (default) 3.3V Short 2-3 2.3.3 Compact Flash Mode Selection: JP3 Options Settings Short 1-2 (default)

  • Page 17: Com1 Mode: Jp5

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.3.5 COM1 Mode: JP5 Options Settings Short 1-2 (default) RS-232 Short 3-4,7-8 RS-422 Short 5-6,7-8 RS-485 2.3.6 COM1 Mode: JP6 Options Settings Short 1-3,2-4 RS-422,RS-485 Short 3-5,4-6(default) RS-232 2.3.7 PS2 Keyboard Mode: JP7 Options Settings Short 1-2,3-4...

  • Page 18: Lpt Mode Selection: Jp9

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.3.9 LPT Mode Selection: JP9 Options Settings Short 1-2 (default) Normal Short 2-3 +12V Or +5V 2.3.10 COM1.COM2.COM3.COM4 Mode: JP10.JP11.JP12.JP13 COM1 (CN20) JP11 COM2 (CN8) JP10 Pin 1=12V Short 1-3 Pin 1=12V Short 1-3 Pin 1=5V...

  • Page 19: Lpt Mode Selection: Jp14

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.3.11 LPT Mode Selection: JP14 JP14 Options Settings Short 1-2 (default) Normal Short 2-3 +12V Or +5V 2.3.12 LVDS Voltage Selection: JP15 JP15 Options Settings Short 1-2 (default) 3.3V Short 2-3 2.3.13 PS2 Mouse Mode: JP16 JP16 Options...

  • Page 20: Connectors

    Some problems encountered by your system may be a result from loose or improper connections. Ensure that all connectors are in place and firmly attached. The following table lists the function of each connector on the SBC86620 Series. Connectors Label...

  • Page 21: Atx Power Connector: Cn1

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.1 ATX Power Connector: CN1 Signal Signal 3.3V 3.3V 3.3V -12V PS_ON PW_OK 5V_SB 2.4.2 Flat Panel Bezel Connector:CN2 Power LED This 3-pin connector, designated at Pins 1 and 5 of CN2, connects the system power LED indicator to its respective switch on the case.

  • Page 22: Compactflash Connector: Cn3

    HDD LED. Pins 13 is -, and pin 14 is assigned as 2.4.3 CompactFlash Connector: CN3 The SBC86620 Series is equipped with a CompactFlash disk socket on the solder side and it supports the IDE2 interface CompactFlash disk card.

  • Page 23: Lvds Backlight Connector: Cn4

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Data 5 Data 13 Data 6 Data 14 Signal Signal Data 7 Data 15 CS0# CS1# Address 10 VS1# ATASEL IORD# Address 9 IOWR# Address 8 Address 7 INTR Address 6 CSEL# Address 5 VS2#...

  • Page 24: Mini Pci Connector: Cn5

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.5 Mini PCI Connector: CN5 Mini-PCI Connector Pin Assignment Signal Signal RING LAN_RD+ LAN_TD+ LAN_RD- LAN_TD- RJ45 termination RJ45 termination RJ45 termination RJ45 termination LAN_LED1+ LAN_LED2+ LAN_LED1- LAN_LED2- CHGND RESERVED INTB# 3.3V INTA#...

  • Page 25: Sm Bus: Cn6

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Signal Signal PERR# DEVSEL# C/BE1# AD14 AD15 AD13 AD12 AD11 AD10 AD09 AD08 C/BE0# AD07 3.3V 3.3V AD06 AD05 AD04 RESERVED AD02 AD00 RESERVED AD01 100 RESERVED 101 GND 102 GND 103 RESERVED 104 RESERVED 105 RESERVED...

  • Page 26: Digital I/O Port (Dio): Cn7

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.7 Digital I/O Port (DIO): CN7 The board is equipped a digital I/O connector CN7 that meets a system customary automation control needs. The digital I/O can be configured to control the cash drawer, or to sense the warning signal of an Uninterrupted Power System (UPS), or to perform the store security control.

  • Page 27: Keyboard Connector: Cn11

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.9 Keyboard Connector: CN11 Signal +12V CLOCK DATA 3 4 5 6 7 CLOCK1 DATA1 2.4.10 Mouse Connector: CN12 Signal CLOCK DATA CLOCK1 DATA1 Jumpers and Connectors...

  • Page 28: Usb Connector: Cn14

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.13 USB Connector: CN14 The Universal Serial Bus (USB) connector on the SBC86620 is for installation of peripherals supporting the USB interface. CN14 is 10- pin standard USB connector. USB2 and USB3 Signal Signal Ground (GND)

  • Page 29: Usb*2+Lan Connector: Cn16

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.15 USB*2+LAN Connector: CN16 Signal Signal L1 NC G2 Ground (GND) L2 Tx+ G3 Ground (GND) L3 Tx- G4 Ground (GND) L4 Rx+ G5 Ground (GND) L5 Rx- G6 Ground (GND) L6 NC G7 Ground (GND) L7 NC...

  • Page 30: Keyboard And Ps/2 Mouse Connectors: Cn18

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.17 Keyboard and PS/2 Mouse Connectors: CN18 The SBC86620 provides a keyboard and Mouse interface that is a DIN connector . PS/2 Mouse Clock PS/2 Mouse Data Keyboard Clock Keyboard Data 2.4.18 Phone Jack Connector: CN19 Signal Signal...

  • Page 31: Com1 Port Connector: Cn20

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.19 COM1 PORT Connector: CN20 COM1 Signal Data Carrier Detect (DCD) Data Set Ready (DSR) Receive Data (RXD) Request to Send (RTS) Transmit Data (TXD) Clear to Send (CTS) Data Terminal Ready (DTR) Ring Indicator (RI) Ground (GND) 2.4.20 Speaker Connector: CN21, CN22...

  • Page 32: Lcd Connector: Cn23_Lcd1

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Signal Signal Signal No connector HDC CS0 # HDC CSI # HDD Active # 2.4.22 LCD Connector: CN23_LCD1 Signal Signal No connector +12VM VDDM VDDM FPDISP B0 (P0) B1(P1) B2 (P2) B3 (P3) B4 (P4) B5 (P5)

  • Page 33: Lvds Flat Panel Connector: Cn23_Lvds1

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.23 LVDS Flat Panel Connector: CN23_LVDS1 The LVDS interface which is with 40-pin connector supports 18/24-bit single/dual channel type of LCD. Signal Signal VCCM VCCM VCCM VCCM VCCM VCCM N.C. N.C.

  • Page 34: Vga Connector: Vga1

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2.4.24 VGA Connector: VGA1 VGA1 is a standard 15-pin pin DB15 connector commonly used for the CRT VGA display. Signal Signal Signal Green Blue AGND AGND AGND 11 N/A 12 DDC DAT Horizontal 14 Vertical Sync 15 DDC CLK...

  • Page 35: Parallel Port: Lpt1

    Data 5 Data 6 Data 7 Acknowledge# Busy Paper Empty# Printer Select 2.4.27 PICMG compliant PCI Connector: PL1 The SBC86620 Series provides a free PICMG compliant PCI slot for 32-bit/33MHz PCI device extension. Signal Signal -12V TRST# Reserved +12V Reserved...
  • Page 36 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Signal Signal REQ1# GNT3# Reserved CLKA GNT1# RST# CLKB GNT0# REQ0# REQ2# AD31 AD30 AD29 Reserved AD28 AD27 AD26 AD25 Reserved AD24 CBE3# GNT2# AD23 +3.3V AD22 AD21 AD20 AD19 Reserved AD18 AD17...

  • Page 37: Usb (Disk On Module) Connector: Usb1

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Signal Signal AD12 AD11 AD10 AD09 AD08 CBE0# AD07 Reserved Reserved AD06 AD05 AD04 AD03 AD02 AD01 Reserved Reserved 2.4.28 USB (Disk On Module) Connector: USB1 Signal Signal VCC5 Ground (GND) 10 NC Jumpers and Connectors...
  • Page 38 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual MEMO Jumpers and Connectors...

  • Page 39: Chapter 3 Hardware Description

    CPU. BIOS System BIOS used on the SBC86620 Series is Phoenix-Award Plug and Play BIOS. The SBC86620 Series contains a single 4Mbit Flash. System Memory The SBC86620 Series industrial CPU card supports one 200-pin DDR SODIMM socket for a maximum memory of 1GB DDR SDRAMs.

  • Page 40: I/O Port Address Map

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual I/O Port Address Map It has a total of 1KB port addresses available for assignment to other devices via I/O expansion cards. Address Devices 000-01F DMA controller #1 020-03F Interrupt controller #1 040-05F Timer 060-06F...

  • Page 41: Interrupt Controller

    Geode GX3 Mini ITX Board User’s Manual Interrupt Controller The SBC86620 Series is a 100% PC compatible control board. It consists of 16 interrupt request lines. Four out of the sixteen can either be programmable. The mapping list of the 16 interrupt request lines is shown on the following table.
  • Page 42 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual MEMO Hardware Description...

  • Page 43: Chapter 4 Phoenix-Award Bios Utility

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual C h a p t e r 4 Phoenix-Award BIOS Utility The Phoenix-Award BIOS has a built-in Setup program that allows users to modify the basic system configuration. This type of information is stored in a battery-backed RAM (CMOS RAM) that retains the Setup information each time the power is turned off.

  • Page 44: Control Keys

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Control Keys Moves cursor to the previous item Up arrow Moves cursor to the next item Down arrow Moves cursor to the item on the left hand Left arrow Move to the item in the right hand Right arrow Main Menu -- Quits and deletes changes into CMOS Esc key...

  • Page 45: The Main Menu

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual The Main Menu Once you enter the Award BIOS CMOS Setup Utility, the Main Menu will appear on the screen. The Main Menu allows you to select from ten setup functions and two exit choices. Use the arrow keys to select the setup function you intend to configure then press <Enter>...

  • Page 46: Standard Cmos Setup Menu

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Standard CMOS Setup Menu The items in Standard CMOS Setup Menu are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp>...
  • Page 47 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual IDE Primary Master/Primary Slave The categories identify the types of one channel that have been installed in the computer. There are 45 predefined types and 2 users definable types are for Enhanced IDE BIOS. Type 1 to Type 45 is predefined.
  • Page 48 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Halt On This field determines whether the system will halt if an error is detected during power up. The system boot will halt on any error detected. No errors (default) Whenever the BIOS detect a non-fatal error, the All errors system will stop and you will be prompted.

  • Page 49: Advanced Bios Features

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Advanced BIOS Features This section allows you to configure and improve your system and allows you to set up some system features according to your preference. CPU Internal Cache This option speed up memory access. However, it depends on the CPU/chipset design.
  • Page 50 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual First/Second/Third Boot Device These items allow the selection of the 1 , and 3 devices that the system will search for during its boot-up sequence. The wide range of selection includes Floppy, LS120, ZIP100, HDD0~3, SCSI, and CDROM.
  • Page 51 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Typematic Delay (Msec) This option sets the display time interval from the first to the second character when holding a key. The default value is “250”. 250 msec 500 msec 750 msec 1000 1000 msec...

  • Page 52: Advanced Chipset Features

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Small Logo (EPA) Show Set the Logo (EPA) show or not. The default value is “Disabled”. Advanced Chipset Features Since the features in this section are related to the chipset on the CPU board and are completely optimized, you are not recommended to change the default settings in this setup table unless you are well oriented with the chipset features.
  • Page 53 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Interleave Select Select the address interleaving mode. The choice: HOI, LOI. The GLMC(GeodeLink™ Memory Controller) module supports two address translations depending on the method used to interleave pages. High Order Interleaving (HOI) uses fixed upper address bits to map the GLIU address to a component bank.
  • Page 54 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual VSYNC Polarity Active The choice: HI, LOW. SHFCLK Active Period Select the shift clock (SHFCLK) to be either free running, or active only during the display period. Some TFT panels recommend keeping the shift clock running during the retrace time.

  • Page 55: Integrated Peripherals

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Integrated Peripherals This section allows you to configure your SuperIO Device, IDE Function, Onboard Device, and ITE8888. Onboard Serial Port 1/Port 2 Select an address and corresponding interrupt for the first and second serial ports.
  • Page 56 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Serial Port 3/Port 4 Use IRQ Select corresponding interrupt for the third and fourth serial ports. The options available are IRQ10, IRQ11. IDE Primary Master/Slave PIO The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports.
  • Page 57 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual ITE8888 Configuration Positively Decode I/O Press Enter to set ITE8888 decode I/O function. Positively Decode I/O 0/1/2/3/4/5 IO Space 0 Size This item allows the user to enable/disablee the Positively Decode I/O 0/1/2/3/4/5.
  • Page 58 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual IO Space 0/1/2/3/4/5 Size This item allows the user to decide the Size of I/O Space 0/1/2/3/4/5. The options available are 1,2,4,8,16,32,64,128. IO Base Address 0/1/2/3/4/5 This item allows the user to decide the Base Address of Decode I/O 0/1/2/3/4/5.

  • Page 59: Power Management Setup

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Power Management Setup The Power Management Setup allows you to save energy of your system effectively. It will shut down the hard disk and turn OFF video display after a period of inactivity. ACPI Function This item allows you to enable/disable the Advanced Configuration and Power Management (ACPI).
  • Page 60 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Suspend Mode After the selected period of system inactivity (1 minute to 1 hour), all devices except the CPU shut off. The default value is “Disabled”. System will never enter SUSPEND mode Disabled Defines the continuous idle time before the 1/2/4/6/8/10/20/30/4...

  • Page 61: Pnp/Pci Configuration Setup

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.10 PnP/PCI Configuration Setup This section describes configuring the PCI bus system. PCI, or Personal Computer Interconnect, is a system which allows I/O devices to operate at speeds nearing the speed the CPU itself uses when communicating with its own special components.
  • Page 62 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Resources Controlled By The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play-compatible devices. If you select Auto, all the interrupt request (IRQ), DMA assignment, and Used DMA fields disappear, as the BIOS automatically assigns them.

  • Page 63: Pc Health Status

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.11 PC Health Status Current CPU Temperature These read-only fields reflect the functions of the hardware thermal sensor that monitors the chip blocks and system temperatures to ensure the system is stable. Phoenix-Award BIOS Utility...

  • Page 64: Load Fail-Safe Defaults

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.12 Load Fail-Safe Defaults This option allows you to load the troubleshooting default values permanently stored in the BIOS ROM. These default settings are non- optimal and disable all high-performance features. To load BIOS defaults value to CMOS SRAM, enter “Y”.

  • Page 65: Load Optimized Defaults

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.13 Load Optimized Defaults This option allows you to load the default values to your system configuration. These default settings are optimal and enable all high performance features. To load SETUP defaults value to CMOS SRAM, enter “Y”. If not, enter “N”.

  • Page 66: Set Supervisor/User Password

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.14 Set Supervisor/User Password You can set either supervisor or user password, or both of then. The differences between are: Supervisor password: can enter and change the options of the setup menus.

  • Page 67: Save & Exit Setup

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.15 Save & Exit Setup This allows you to determine whether or not to accept the modifications. Typing “Y” quits the setup utility and saves all changes into the CMOS memory.

  • Page 68: Exit Without Saving

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4.16 Exit Without Saving Select this option to exit the Setup utility without saving the changes you have made in this session. Typing “Y” will quit the Setup utility without saving the modifications. Typing “N” will return you to Setup utility.

  • Page 69: Appendix A Watchdog Timer

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual A p p e n d i x A Watchdog Timer Watchdog Timer Setting The watchdog timer makes the system auto-reset while it stops to work for a period. The integrated watchdog timer can be setup as system reset mode by program.
  • Page 70 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual ; IF to disable WDT: O 2E 30 O 2F 00 ; Can be disable at any time Timeout Value Range 1 to 255 Minute / Second Program Sample Watchdog timer setup as system reset with 5 second of timeout 2E, 87 2E, 87 2E, 07...

  • Page 71: Appendix B Installation Of Drivers

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual A p p e n d i x B Installation of Drivers Installation of AES Driver Click “Device Manager”. Installation of Drivers...
  • Page 72 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2. Click “Update Driver”. 3. Click on next Installation of Drivers...
  • Page 73 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4. Click on next 5. Select AES Driver Folder then Click on next. Installation of Drivers...
  • Page 74 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 6. Click on Finish 7. Geode LX AES Crypto Driver installed finish. Installation of Drivers...
  • Page 75 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Installation of Audio Driver 1. Open device manage, right click on Multimedia Audio Control and click on update Driver. Installation of Drivers...
  • Page 76 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2. Click on next 3. Click on next Installation of Drivers...
  • Page 77 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4. Select Audio Driver Folder then Click on next. 5. Click “Continue Anyway” Installation of Drivers...
  • Page 78 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 6. Click Finish 7. Audio Driver installed finish. Installation of Drivers...
  • Page 79 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Installation of LAN driver 1. Click Setup Installation of Drivers...
  • Page 80 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2. Click on Next 3. Click on Install Installation of Drivers...
  • Page 81 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4. Click on Finish Installation of Drivers...
  • Page 82 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Installation of PCI Bridge Driver 1. Open device manage, right click on Other PCI Brige Device and click on update Driver. Installation of Drivers...
  • Page 83 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2. Click on next 3. Click on next Installation of Drivers...
  • Page 84 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4. Search the right directory of PCI Bridge for ITE8888 driver. 5. Click on Finish Installation of Drivers...
  • Page 85 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Installation of VGA Driver 1. Open device manage, right click on Video Controller and click on update Driver. Installation of Drivers...
  • Page 86 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 2. Click on Next 3. Click on next Installation of Drivers...
  • Page 87 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 4. Click on next 5. Click on Continue Anyway Installation of Drivers...
  • Page 88 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual 6. Click on Finish * After installed all Driver. Please reboot the system. Installation of Drivers...

  • Page 89: Appendix C Digital I/O

    ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual A p p e n d i x C Digital I/O Using the Digital Input Function Start ↓ Un-Lock SuperI /O: O 4E 87 ; Un-lock super I/O O 4E 87 ; Un-lock super I/O ↓...
  • Page 90 ® SBC86620 AMD Geode GX3 Mini ITX Board User’s Manual Using the Digital Output Function Start ↓ Un-Lock SuperI /O: O 2E 87 ; Un-lock super I/O O 2E 87 ; Un-lock super I/O ↓ SelectMultiplexed pin to GPIO Function : O 2E 2A O 2F FF ↓...
