2.1 Jumper & Connector Quick Reference
Table
COM Port Connector.......................................
RS232/422/485 (COM2) Selection....................
Keyboard/Mouse Connector............................
ATKeyboard/Mouse Selection........................ .
External Keyboard Connector.........................
Reset Connector.............................................
Hard Disk Drive LED Connector.......................
ATX Power Button.........................................
External Speaker Connector............................
Power LED Connector.....................................
KeyLock Connector.......................................
Clear CMOS Data Selection............................
CPU Fan Connector.......................................
System Fan Connector..................................
VGA Connector..............................................
Hard Disk Drive Connector..............................
ACPI Connector
Floppy Disk Drive Connector...........................
Printer Connector...........................................
Universal Serial Bus Connector........................
IrDA Connector ............................................
LAN Connector .............................................
GigaLAN (LAN2) Enable/Disable Selection.......
Memory Installation.........................................
Reset/NMI/Clear Watchdog Selection...............
Sound Connector...........................................
CD Audio-In Connector..................................
Compact Flash Card Master/Slave Selection ...
Backplane 3.3V Voltage Selection...................
Digital IO Connector.....................................
LVDS Connector..........................................
LVDS Voltage Selection.................................
Inverter Connector.......................................
Reserved Pin................................................
10
® ®
SBC81870 Intel Pentium
Hardware Configuration
M w/ DDR/VGA/Dual LAN
COM1, COM2
JP2
DIN1
JP16
EXKB1
JPANEL1 (13,15)
JPANEL1 (9,11)
JPANEL1 (14,16)
JPANEL1 (1,3,5,7)
JPANEL1
(8,10,12)
JPANEL1 (17,18)
JP13
JCFAN1
JSFAN1
VGA1
IDE1, IDE2
ACPI1
FDD1
LPT1
USB1, USB2
IRDA1
LAN1, LAN2
JP9
DIM1, DIM2
JP18
JP4
JCDIN1, JCDIN2
JP5
JP15
DIO1
J2
JP7
J3
JP10, J6, JP1,JP6
