2.26 GIGALAN (LAN2) Enable/Disable
Selection
JP9: GigaLAN (LAN2) Enable/Disable Selection.
The selections are as follows:
FUNCTION
Enable
Disable
Manufacturing Default is set as open.
2.27 ACPI Connector
ACPI1: ACPI Connector.
The pin assignments are as follows:
32
® ®
SBC81870 Intel Pentium
JUMPER SETTING
(pin closed)
OPEN
2-3
E
P X
P
S W T
W
B _ S
G _ G
5 O M
N P N
V N I
D N D
6 5 4 3 2 1
Hardware Configuration
M w/ DDR/VGA/Dual LAN
JUMPER
ILLUSTRATION
