Install The Server (2-Post, 19-Inch Hardmount Rack Kit) - Oracle Netra Server X3-2 Installation Manual

19-Inch, 2-Post Hardmount Rack Screws
TABLE:
Quantity Description
10 M5 x 7 SEM screws
6 M3 x 8 SEM screws
10 M5 x 12.7 mm screws
10 M6 x 13 mm screws
9 M6 square clip nuts
12 10-32 x 0.5 in. combo head screws
12 12-24 x 0.5 in. combo head screws
Related Information
"Install the Server (2-Post, 19-Inch Hardmount Rack Kit)" on page 53
■
"Tools Needed for Installation" on page 22
■
"Handling Precautions" on page 20
■
"Rack Cautions" on page 23
■
▼ Install the Server (2-Post, 19-Inch Hardmount
Rack Kit)
Note – The 19-inch, 2-post rackmount kit supports rack web thicknesses (the width
of the rack post) of 3 in. (76.20 mm), 4 in. (101.6 mm), and 5 in. (127 mm).
1. Gather the required tools.
See "Tools Needed for Installation" on page
2. Read the server cautions.
See "Handling Precautions" on page 20
3. Read the rack cautions and stabilize the rack.
See "Rack Cautions" on page 23
4. Using four of the M5 x 7 SEM screws for each side bracket, secure the side
brackets to the sides of the server.
Where Used
8 for side brackets, 2 extra
4 for rear plates, 2 extra
10 for rack, if appropriate
10 for rack, if appropriate
9 for rack, if appropriate
12 for rack, if appropriate
12 for rack, if appropriate
22.
and "ESD Precautions" on page
and "Stabilize the Rack" on page
Installing the Server in a 2-Post Rack
21.
24.
53
