Cyclic data transmission

2 ASDU for measured values

2 ASDU for single point information (64 states in each ASDU).

1 ASDU for Double point information (16 states for Switchgear).

Spontaneous Transmission:

2 ASDU for measured values (timing is set in Cyclic Meter Period, 0 means no spontaneous transmission).

1 ASDU for single point information in the time the event is produced (128 points in user map).

1 ASDU for Double point information in the time the event is produced (16 Switchgear information).

Clock synchronization:

Command transmission:

Acquisition of transmission delay:

F650 Digital Bay Controller

D.1 IEC 60870-5-104 PROTOCOL

D.1.3 BASIC APPLICATION FUNCTIONS
