IPNext 190 System Installation Guide

Verifying IP, Default Route Configuration Settings

The followings display the network configuration for the basic communication. Use ping test to the default
Ipnext190 to check the network connection
IP-PBX# configure terminal
IP-PBX(config)# interface Fastethernet 0/0
IP-PBX(config-if)# ip address 172.17.201.115 255.255.0.0
IP-PBX(config-if)# exit
IP-PBX(config)# ip route 0.0.0.0 0.0.0.0 172.17.1.1
IP-PBX(config)# end
IP-PBX#
IP-PBX#
IP-PBX# write
Proceed with write? [confirm]
Building configuration...
[OK] Configuration saved to flash:/apos.cfg
IP-PBX#
IP-PBX# ping 172.17.1.1
PING 172.17.1.1 (172.17.1.1): 56 data bytes
64 bytes from 172.17.1.1: icmp_seq=0 ttl=255 time=0 ms
64 bytes from 172.17.1.1: icmp_seq=1 ttl=255 time=0 ms
64 bytes from 172.17.1.1: icmp_seq=2 ttl=255 time=0 ms
64 bytes from 172.17.1.1: icmp_seq=3 ttl=255 time=0 ms
64 bytes from 172.17.1.1: icmp_seq=4 ttl=255 time=0 ms
--- 172.17.1.1 ping statistics ---
5 packets transmitted, 5 packets received, 0% packet loss'
round-trip min/avg/max = 0/0/0 ms
IP-PBX#

Table 3-79 IP, Default Route Configuration Settings

AddPac Technology Proprietary & Documentation
132 - 99
