IPNext 190 System Installation Guide
Console Port
On the Front, the IPNext190 has one RJ-45 type of RS-232C Female DCE connector interface of one CPU
on the front. Through this port, you can perform initial setups, monitoring and debugging. The cable and
connector are required. Refer to the appendix of this guide for the cable and pin specifications for RS-232C
console cable.
