IPNext 190 System Installation Guide
If a static prevention waist strap is available, strap it around the wrist and earth the cord before
operating the equipment.
If no waist tap is available, stand on the ground and hold a metal part of the chassis will help prevent
static electricity.

Site Requirements in General

The IPNext190 is ready for use where electronic products are used. However, a location with the following
conditions is recommended for the maximum performance.
A level and well ventilated location is recommended.
Secure the equipment safely where intended to install.
Avoid placing objects on top of the equipment.
Install the equipment in a cool location avoiding direct sunlight.
Maintain distance from flammable, chemical, or magnetic objects

Required Tools and Equipment

This procedure is to follow EIA standards and other EMI regulations when you install the gateway
The following section describes the Ethernet Cable, and the Console Cable which can be connected to the
IPNext190.
Some cables and equipment are not included and your need to purchase them separately. Please prepare the
following tools and equipment
A standard screw driver set
The cables to connect LAN and console port
RJ-45 to RJ-45 connection type for LAN port
RS-232C cable type for console with RJ-45 connector type (included in the package)
Ethernet Port
The IPNext PBX Series have two RJ-45 types of Ethernet ports on the rear panel and also has LEDs
indication the port status. Use the standard cable and connector types of this port to access LAN. Refer to
Appendix B for pin details for the Ethernet cable.
AddPac Technology Proprietary & Documentation 132 - 26
