IPNext 190 System Installation Guide

Uploading APOS

Use ftp from DOS window of PC to upload APOS for the Ipnext190. Press 'Start' of the window
and enter 'cmd' in Run widow, then DOS window opens up.
D:\ >dir
2008-08-14 15:21p
2006-08-14 15:21p
2008-08-14 15:21p
D:\>
D:\> ftp 172.17.113.50
Connected to 172.17.113.50.
220 IP-PBX FTP server (Version 8.47.010) ready.
User (172.17.113.50:(none)): root
331 Password required for root.
Password:
230 User root logged in.
ftp> binary
200 Type set to I.
ftp> hash
Hash mark printing On ftp: (2048 bytes/hash mark) .
ftp> put ipnext190_g2_v8_47_024.bin => ipnext190_g2_v8_47_024.bin => Upload the file
200 PORT command successful.
150 Opening BINARY mode data connection for 'ipnext190_g2_v8_47_010.bin'.
################################################################################
------------ 중략 -----------
#########################################################################
226 Transfer complete.
ftp: 5229160 bytes sent in 1.92Seconds 2720.69Kbytes/sec.
ftp> quit
221 Goodbye. => Do not reboot the IPNext PBX until the message is displayed as 'The system software is
updated' at the console connected to the IPNext PBX, even after the message of 'Goodbye' is displayed.
D:\>

Table 3-82 APOS Upgrade (DOS Screen)

<DIR> .
<DIR> ..
5,229,160 ipnext190_g2_v8_47_024.bin
=> Access to the server
=> Change to binary mode
=> Display Hash mark
AddPac Technology Proprietary & Documentation 132 - 105
