IPNext 190 System Installation Guide

Booting Process and Operation Fundamentals

Before powering on the IPNext190, please be familiar with the following booting
process:
The IPNext190 goes though a self-testing process and check the basic operation of CPU, memory and
interfaces
As the Boot Loader starts up, it looks for the image file which can be proper to the IPNext190. At the
default configuration, the IPNext PBX series are set to load the software from the flash memory.
If IPNext190 can not find the software image file from the flash memory, the stand-by at the boot
mode until they can download the proper software (at this time, FTP or TFTP protocol can be used to
download the proper software for the IPNext190).
The IPNext PBX series operate basing on the configured settings which are saved after the software is
downloaded. Without the saved settings, the IPNext PBX Series
administrator should save the configured setting for the proper network operation.
During the installation, the IPNext PBX Series need to be powered on after the interface connection is
finished. The power adapter is to be connected for the power supply after the connection is performed first.
Please do not connect the interfaces after connecting the power adapter. The IPNext PBX Series
automatically recognize the different voltage of 110V and 220V supplied from the adapter.
The following message is displayed after the IPNext190 is rebooted normally:
System Bootstrap, Version 1.2
Decompressing the image:
###########################[OK]
?
System Boot Loader, Version 5.1.3
Copyright (c) by AddPac Technology Co., Ltd. Since 1999.
[DUAL-BOOT] Start application (0xbc000000)...
AddPac Technology Proprietary & Documentation
operates at default. So the
