AddPac AP-IPNext SMT User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
AP-IPNext SMT Manual
AddPac Technology OSTS
2010 AddPac, All Right reserved. AddPac Technology and AddPac logo are trademarks of AddPac Technology
intellectual property.

Advertisement

loading
Need help?

Need help?

Do you have a question about the AP-IPNext SMT and is the answer not in the manual?

Questions and answers

Related Manuals for AddPac AP-IPNext SMT

Summary of Contents for AddPac AP-IPNext SMT

  • Page 1 AP-IPNext SMT Manual AddPac Technology OSTS 2010 AddPac, All Right reserved. AddPac Technology and AddPac logo are trademarks of AddPac Technology intellectual property.
  • Page 2 1. Introduction of IP-Next Series 2. Initial Settings 3. User’s Registration 4. Setup for Supplementary Service (IPNext) 5. Setup for Supplementary Service (External Servers) 6. Appendix A. IPNext HDD setup (Fdisk / format / Raid) B. IPNext Initialize C. IPNext Redundant Configuration AddPac Technology...
  • Page 3 3) FXO LED Front View POWER LED LAN 0,1 LED FXO LED 2) LAN0,1 LED 1) FastEthernet(Wan), 2) Console. 3) FXO 0 Parts of Rear Side Power Switch 1) Power, 2) FastEthernet(Lan) 3) USB 4) FXO 1 Rear Side AddPac Technology...
  • Page 4 • Auto Attendant & • Calling Number and Name Identification Features • Call Transfer – Blind, Consult by Softkey • Call Waiting Indication Call Swapping by Softkey • Call Hold by Softkey • Conference Control (internal/external MCU) AddPac Technology Proprietary &...
  • Page 5 Major Features of IPNext Features Contents Advanced • with AddPac IP phone, Video Phone, etc Features • Plug and Play with Auto Discovery Function (SSCP) with AddPac IP phone, • Softkey Map Download and Control (SSCP) Video Phone, etc • Time and Date Setting •...
  • Page 6 • Support Voice Mail with IVR • Access from Remote Site via Trunk Support Voice Mail • Voice Mail Notification Support • Ad-Hoc Conference • Dial-Out Conference Conference • Meet-me Conference • Multiple External MCU Support (Video, Audio, etc) : AP-MC1000 AddPac Technology Proprietary &...
  • Page 7 IP-PBX • Auto Config & Upgrade Miscellaneous • Personal Directory (Smart Messenger) Function • IPv4/IPv6 Dual Stack • Management Routing Basic Routing - Telnet, FTP, TFTP, SNMP, Syslog support - Packet filtering (Access-list) - Static Routing AddPac Technology Proprietary &...
  • Page 8 • Standard SNMP Agent (MIB v2) Support Network • Traffic Queuing Management • Remote Management using Console, Telnet. • Standard & Extended IP Access List Security • Enable/Disable for Specific Protocols Functions • Auto-disconnect for Telnet/Console Sessions AddPac Technology Proprietary &...
  • Page 9 • IP Traffic Statistics with Accounting • Debugging command • DHCP Server/Client • Network Address Translation (NAT) Function Other • Port Address Translation (PAT) Function Scalability Features • Cisco Style Command Line Interface(CLI) • Network time Protocol(NTP) Support AddPac Technology Proprietary &...
  • Page 10 • Operating Temperature: 0°C ~ 50°C (32° ~ 122°F) Operation • Storage Temperature: -40°C ~ +85°C (-40° ~ +185°F) Environments • Relative Humidity: 5% ~ 95% (Non-condensing) • 38(H) * 182(W) * 182(D) Dimensions • 0.46 Kg Weight AddPac Technology Proprietary &...
  • Page 11 Function of Signaling / Media Proxy ( RTP Proxy) IPNext NAT router NAT router Private PSTN Private AddPac Technology Proprietary &...
  • Page 12 Smart Multimedia Manager IPNext addpac propriety SMM message Local Area PSTN Major Functions • IP-Next Registration all setups related to user. • IP-Next all setups related to service • IP-Next status review • IP-Next message trace AddPac Technology Proprietary &...
  • Page 13 The structure allowing one of two IP PBX’s become master and the other one Active-Standby become disbled Terminal SSCP The terminal using AddPac Specific Terminal Control Protocol. AP-IP-XXX, AP- Registration VP-XXX series come under this sub- category Generic SIP terminal Supporting linking protocol of SSCP and general SIP terminal or SIP gateway with Multiple Ports Trunk Gateway or Service Provider’s SIP server for interoperability with PSTN...
  • Page 14 Trunk gateway routing pattern Routing pattern input(Digit map) Call priority / authority / MRBT/CID… Call Control SIP Proxy Server General location/device profile/partition/RTP Proxy/Network domain/SIP ID/password/DTMF relay method and other setups Register (option) Register Phone number AddPac Technology Proprietary & Documentation...
  • Page 15 Used for setting ranks of outgoing calls of each group/ subscriber Number Translation Rule Registering patter list of change in number Routing group Routing Tag for Trunk interface Routing List Routing pattern list to be applied to Routing Group AddPac Technology Proprietary & Documentation...
  • Page 16 Initial Setting 1. Basic configuration(CLI) 2. LdapClient set up(CLI) AddPac Technology...
  • Page 17 IP-PBX# config t IP-PBX(config)# no username root IP-PBX(config)# username root password addpac administrator % Caution: After no username is set and rebooted, the root account disappears and remote access becomes impossible. The only way to access is automatic login, the authority at this time is administrator % Must save after setup.
  • Page 18 Booting messages in IPNext(via console) System Bootstrap, Version 1.2 Decompressing the image: ##########################[OK] ?System Boot Loader, Version 5.1.6 Copyright (c) by AddPac Technology Co., Ltd. Since 1999. [DUAL-BOOT] Start application (0xbd000000)... System Bootstrap, Version 1.2 Decompressing the image: ################################################# AddPac IP-PBX Series (IPNext_G2) 32BIT RISC Processor With 125MHz Clock 128 Mbytes System Memory.
  • Page 19 Basic configuration • Connect IPNext Welcome, APOS(tm) Kernel Version 8.xx.xxx. Copyright (c) 1999-2008 AddPac Technology Co., Ltd. Login: root (Login ID) Password:****** (Default login Password : router) IP-PBX> • Set hostname IP-PBX> enable IP-PBX# configure terminal IP-PBX(config)# hostname <Name> (set Hostname ) IP-PBX(config)# •...
  • Page 20 (Set ip address) Example) IP-PBX(config)# ip address 172.17.109.200 255.255.0.0 Set Gateway • IP-PBX> enable IP-PBX# configure terminal (set Gateway ‘s ip) IP-PBX(config)# ip route <Destination Network IP> <Wildcard Mask><Gateway IP> IP-PBX(config)# Example) IP-PBX(config)# ip route 0.0.0.0 0.0.0.0 172.17.1.1 AddPac Technology...
  • Page 21 IP-PBX(config)# network-domain interface ip FastEthernet 0/0 domain public IP-PBX(config)# network-domain interface ip FastEthernet 0/1 domain private * FastEthernet 0/0 set Public IP with “Public "domain name FastEthernet 0/1 set Private IP with “Private” domain name for terminal which have Public IP and Private. AddPac Technology...
  • Page 22 User’s Registration 1) Creating Subscriber’s Extension Numbers 2) Creating Subscriber’s Extension Users 3) Opening of Subscriber’s Terminals 4) Registering Subscriber’s Terminal 5) Trunk Setup(including Service Provider’s signaling server ) 6) Number Routing table AddPac Technology...
  • Page 23 The Procedure for Registering Subscribers Creating New Subscriber Numbers (Phone Number) Registering to Subscriber Terminal (Terminal) Assigning Subscriber Numbers to Subscriber Terminal Creating Trunk (inbound/outbound SIP Server or TG) Setting up for Number Routing Map Confirming Registration and Testing Calls AddPac Technology...
  • Page 24 SMM Login The Main Page http://172.17.109.201 via explorer “Click” Icon Click ID : root Password : router It can change server port using Setting button If you changed port, need to change IPNext also (via CLI) SMM Main Page AddPac Technology...
  • Page 25 2. Requesting extension numbers (Smart Multimedia Manager) P r o d u c t i o n ( 5 0 0 0 ~ 5 0 0 3 ) 1. The new extension numbers are created Technical Support(6000~6003) AP-IPNext AddPac Technology...
  • Page 26 SMM – Call Manager(Phone Number) • Select Add Phone number menu 3. Input Start number and End number 1. Add Phone Number 2. Select Range Option 4. Push “OK” button for create numbers AddPac Technology...
  • Page 27 SMM – User Management(Phone Users) • User Group Create - Create user Group for management. AddPac Technology...
  • Page 28 Last Name – User ID – User Password – Voice Mail Password 2. Assign phone number for each User – Select the number for user using find button 3. Set Nick name which will use in Smart Messenger AddPac Technology...
  • Page 29 Please refer to the next page for more details of setting up IP Phone. Local Area Requesting Requesting Requesting Requesting Requesting registration registration registration registration registration Business Administration R&D Sales Production Technical Support X1000 X2000 X3000 X5000 X6000 AddPac Technology Proprietary &...
  • Page 30 3) Go to network menu -> Presence -> Presence Server input IPNext’s IP-address in Presence Server 1 field input “5051” in Server1 port 4) Go to network menu -> Presence -> Presence Setup input User ID, User password then set Presence Enable to “On” AddPac Technology...
  • Page 31 Changing conversation view/ remote view/ local view while on the line Used during the user’s absence (to be released) (14) Absence (15) Voice Mail To listen to voice mail (to be released) (16) HDP Call For using headset (17) SPK Call To use imbedded speaker phone AddPac Technology Proprietary &...
  • Page 32 Setting up AP-VP3 00 by using OSD) 1) Entering <Main Menu> by pressing menu key 2) Moving to <Network> by using direction key. 3) Moving to <Internet> by using direction key(left, right) Pressing “OK” key to enter <Internet> sub-menu AddPac Technology Proprietary &...
  • Page 33 AP-VP300N OSD setting Creating New Subscriber Numbers (testing call connection between extension numbers- Setting up AP-VP3 00 by using OSD) 1) Moving to <SSCP Setup> by using direction key 2) Pressing OK key to enter <SSCP Setup> sub-menu AddPac Technology Proprietary &...
  • Page 34 1. Pressing ‘1’ to change to ‘release’ from <SSCP setup> 2. After moving to <Call-manager1>, IP addresses of Call-Manager (IP-PBX) can be entered. 3. After returning to <SSCP setup>, ‘setup’ can be changed by pressing ‘1’ 4. Completing <SSCO Setup> by pressing ‘OK’ key AddPac Technology Proprietary &...
  • Page 35 AP-VP300N OSD setting Creating New Subscriber Numbers (testing call connection between extension numbers- Setting up AP-VP3 00 by using CLI) configure terminal sscp enable sscp call-manager 1 10.1.1.1 5060 AddPac Technology Proprietary &...
  • Page 36 SMM - Device Management You can request to register those terminals, which has been set up, to IPNext. You can make reference of this registration by entering ‘Device Management > Terminals’ which is shown below: AddPac Technology...
  • Page 37 If you double- click ‘Terminal Name’ you can see the window of ‘Terminal Properties’ opens up as it is shown below: From ‘General’ tab, the basic setup can be made for naming the terminal and automatic registration. After the setup is made in the screen below, you may double-click ‘Phone Number’ for assigning the numbers. AddPac Technology...
  • Page 38 SMM - Device Management The designated port of the terminal can be selected, then the number sources can be referenced by a double- click. Double Click AddPac Technology...
  • Page 39 SMM - Device Management Selecting the number to be assigned to a designated terminal as it is shown in the picture below: Number Assignment The number to be Supporting list assigned to a for recently designated terminal subscribed numbers AddPac Technology...
  • Page 40 SMM - Device Management Confirming the assigned number as it is shown in the picture below Through the procedure of confirmation (authorization granted) by the operator, the designated number can be set automatically to IP Phone AddPac Technology...
  • Page 41 SMM - Device Management After finishing assignment to the designated terminal as it is shown in the picture below, it completes the process of registering the terminal. AddPac Technology...
  • Page 42 In general, when you want to exit to outside, you may press the number 9 and this is one of the cases. The picture below shows the screen and registration information for Trunk Gateway to work. AddPac Technology...
  • Page 43 This is a setup to provide MOG for the terminal requesting hold ⑭ This is a set to provide MOH for interoperability with Nortel’s soft switch This is a setup by force, for using RTP Proxy while the telephone is on the line AddPac Technology...
  • Page 44 Trunk, don’t generate outbound call for each Trunk(IP-PBX) (if you don’t set this ⑦ option, the user’s can be charged both of IP-PBX ) ⑧ Setting up an option for whether Trunk is to interoperate with outbound ⑨ ⑩ AddPac Technology...
  • Page 45 Set for Failed Call Redirection (SIP 302 Moved Temporary) function ① Set IP-address for IP-PBX get happen Failed Call Redirection Messages to ② transfer Set Server’s port information when IP-PBX send Redirection call ③ ④ Set redirection function using specific reason AddPac Technology...
  • Page 46 Select Network Domain (Public / Private) - It depend on T/G’s IP address. Set IP-address Select Signaling Protocol(SIP / H.323) • Call Control Tab Inbound Call Select Number Translation(Incoming call) Outbound Call Calling party presentation or Caller ID DN AddPac Technology...
  • Page 47 This is a function to register SIP Proxy Server for interoperating with the other SIP Proxy Server in outbound. For example, when an outgoing call is made by registering a company telephone number to SIP Proxy Server, this function can be set up to enable the call which has been registered to SIP Proxy Server. AddPac Technology...
  • Page 48 This is a setup to provide MOH for hold request from a terminal ⓑ This is a set up to provide MOH for interoperability with Nortel soft switch This a set up whether to ‘Register’ or not for the Phone Number to be registered to Proxy Server AddPac Technology...
  • Page 49 The list of telephone numbers to be registered to SIP Proxy Server User Name: Registering user name for the telephone number to be authorized Password: Registering password for the telephone number to be authenticated ② Status: status of registering the telephone number ① AddPac Technology...
  • Page 50 Setting up a number of outgoing call by force (ie.: Representative Number) ⑧ Setting up whether to use P-Asserted-Identity header or not ⑨ Setting up whether to use P-Asserted-Identity in SIP From header field Setting up whether Trunk is to interoperate with outbound or not AddPac Technology...
  • Page 51 Set for Failed Call Redirection (SIP 302 Moved Temporary) function ① ② Set IP-address for IP-PBX get happen Failed Call Redirection Messages to transfer ③ Set Server’s port information when IP-PBX send Redirection call ④ Set redirection function using specific reason AddPac Technology...
  • Page 52 • Provide outside Dial Tone – If client want to use out-side dial-tone which provide(Sip-server or G/K) need to check. • Block this Pattern – Set this routing pattern for blocking – Users can’t use this routing pattern AddPac Technology...
  • Page 53 Input Matched Pattern (a condition) Substituted Pattern(a result) Input Matched Pattern [2-9]T Substituted Pattern 02%01%99 User input output 2345 -> 022345 1234 -> 1234 T = no limitation(All number) . = single digit (any number) [] = range AddPac Technology...
  • Page 54 Input Translation pattern Select number translation (can select translation rule before you made it) Called Number Calling Number • Translation rule can set both of Called Number / Calling Number • it can edit Translation rule using “Edit” AddPac Technology...
  • Page 55 SMM – Test call Make Test call Video-Phone(AP-VP300N) with Video Conference Terminals(AP-VC5000) , Smart Communicator with Video-Phone AP-VP300N with PSTN, etc. Local Area PSTN AP-VC5000 AP-VC5000 AP-SMP1000 AP-VP300N AP-VP300N AP2120N AddPac Technology...
  • Page 56 SMM - Setups for Additional Call Services(IPNext) • Additional Call Services – Hunt Group – Pickup Group – Park – Park Group – Music Announcement – Auto Attendant – Service Code – Day Template – Monitoring AddPac Technology...
  • Page 57 When the number 2001 is busy or absent, the call can be delivered to the 2002 When the number 2002 is busy or absent, the call is to be delivered to 2003 When the number 2003 is still busy or absent, the call can not be delivered and is to be terminated. AddPac Technology...
  • Page 58 Setting ‘Hunt Mode’ to ‘Preference’, ‘Simultaneous’, ‘Random’. Selecting the extension number of the subject group by choosing a tab of ‘Phone Number’. Checking whether the call is processed in the order of the setup by dialing from 1001 to 1003. AddPac Technology...
  • Page 59 Group 1 IP 300N 1001 (1) Call 2001 (4) Confersation IP 300N 1002 (3) Group (2) Call 2001 Pickup IP 300N IP 300N IPNext 50 2001 3001 Pickup IP 300N Pickup Group 2 2002 Group 3 IP 300N 3001 AddPac Technology...
  • Page 60 Creating a group extension number of Technical Support division as ‘Pickup Group Number 2999’ Selecting an extension number of the subject group from the tab of ‘Phone Number’. Completing the setup, then dialing from 1000 to 6000 Checking the response on 1000 by calling 6999 from an extension number 2000 AddPac Technology...
  • Page 61 After moving to 1002, you can press the ‘Park’ number The call is connected to 1001. (1)Conversation (2) MOH (2) Parking IP 300N IP 300N 1001 2001 (3) Parking Adress 8000 (5) Group Park (4) Parked Calll IPNext 50 IP 300N IP 300N 1001 2002 AddPac Technology...
  • Page 62 Selecting ‘Call Management>Supplementary Service>Park Address Pool’. Selecting Add Park and setting up ‘Park Number’. Making a call from1000 to 6000. 6000 reposes to the call then pressing ‘Park Number’, then pressing ‘Park Number’ from the other seat and connecting to 1000. AddPac Technology...
  • Page 63 After moving to a seat, you can choose ‘Group Park’, then pick up. The line connected to 1001. (1)Conversation (3) MOH (2) Group Parking IP 300N IP 300N 1001 2001 (4) Parked Calll (5) Group Park IPNext 50 (4) Parked Calll (4) Parked Calll IP 300N IP 300N 1001 2002 AddPac Technology...
  • Page 64 SMM - Park Group Call Park – Park Group -Setup ‘Call Management>Supplementary Service>Park Group’ Setting ‘Park Group Name’ by choosing Add Park Group Selecting the phone to be registered to ‘Park Group’. AddPac Technology...
  • Page 65 Hook off -Local + Remote Dial tone: Dial Tone can furnished form IP Phone during Hook Off and replacing the dial tone by the one which is furnished from Call Manager -Enabling or disabling Announcement when call fail. AddPac Technology...
  • Page 66 Selecting the audio codec which is to be used in Auto Attendant Service. The supporting codec is G.711A/Ilaw and G.729 ⑥ Setting a number of frames for each port Setting up a designated extension number for when ‘0’ is entered from Auto Attendant Service AddPac Technology...
  • Page 67 G.711A/Ulaw and G.729 are the supporting codec. ⑤ Choose the option for video codec to be used for the Unified Messaging ⑥ services ⑦ MPEG4, H.263, H.263+ and H.264 are the supporting codec. Set the number of frames for each Packet AddPac Technology...
  • Page 68 Set up the code to activate Call Forwarding when the phone user is absent ⓓ Set up the code to deactivate Call Forwarding for absence ⓔ Set up the code to deactivate Call Forwarding for absence ⓕ Set up CCBS Cancel CCBS AddPac Technology...
  • Page 69 SMM - Monitoring • Monitoring – Call Service Monitoring – Active Call Monitoring – Call Trace Monitoring Call Service Monitoring Call trace Monitoring AddPac Technology...
  • Page 70 With the information of phone number and host, this feature finds the call flow which has been processed at a glance. To search the data, specify the event source (Menu > Tools > Preferences > Event) and operate. To save the syslog to the SMM, use Save Event Log. CDR enable Result of Call history AddPac Technology...
  • Page 71 SMM provides and reporting functions and the statistical data of Call Usage, Number of Calls, Incompletion Call and Rank, basing of the basic information that IP-PBX provides. Call usage Statistics Number of Call Statistics InCompletion Call Statistics Ranking Statistics AddPac Technology...
  • Page 72 SMM Setups for Additional Call Services(Additional Servers) 1) Conference Management 2) Presence Management 3) IVR Management AddPac Technology...
  • Page 73 IPNext is equipped with a module for voice conference call and an additional device is required for video conferencing call. There are MCU-specific product such as the AddPac MC3000 and MCU imbedded in terminal product such as VC2000. AddPac Technology...
  • Page 74 This is to configure the settings of video for the media type which is Video + Audio. -Terminal : These are the characteristics of video transmitted from the participating Terminals (optional) Layout : Configuration of the layout for video AddPac Technology...
  • Page 75 This is to configure the settings of video for the media type which is Video + Audio. -Terminal : These are the characteristics of video transmitted from the participating Terminals (optional) Layout : Configuration of the layout for video AddPac Technology...
  • Page 76 (4 numeric digits) Configure the settings of video for the media type which is Video + Audio. -Terminal : These are the characteristics of video transmitted from the participating Terminals (optional) -Layout : Configuration of the layout for video AddPac Technology...
  • Page 77 Configure the settings of video for the media type which is Video + Audio. -Terminal : These are the characteristics of video transmitted from the participating Terminals (optional) Layout : Configuration of the layout for video AddPac Technology...
  • Page 78 Select Media type (Audio only, Audio + Video) – Enable Voice Switching • If you enable this function. The speaker video will display larger than others – Close on Chair Out • The Chair disconnect the conference, the room will be destroy. AddPac Technology...
  • Page 79 SMM - Conference Management • Video – Terminal • This function can select Terminals bandwidth, frame rate, pic size. – Layout • Set layout of this conference. AddPac Technology...
  • Page 80 SMM - Conference Management • Select participant for this conference room • Set one number as a Chair(when chair disconnect this conference this conference will be destroy) AddPac Technology...
  • Page 81 (Pressing the right click, you can search and enter the telephone numbers which have been registered) Use the features of Soft Key(Redial, NewCall, Hold, Transfer)on the speed button. This options is possible if Speed Button Type is set to Soft Key AddPac Technology...
  • Page 82 The same profiles are applied for redundancy. Create Presence Group ① General - Input Presence Group Name Boundary - Choose Organization or User Group Speed Button - Add Speed Button profile ② ③ AddPac Technology...
  • Page 83 (resetting, creating, moving and deleting) and message management (moving and deleting). As it is shown in the following figure, the list of unified messaging servers are displayed by choosing the menu (Unified Messaging Management > System > Unified Messaging Server): AddPac Technology...
  • Page 84 The server file can be deleted after notification Choose the option for blocking the message box for the failed password entry. A number of password entries can be specified. If the message box is blocked, the message can not be left or verified. AddPac Technology...
  • Page 85 Unified message box references, searches or manages all the message boxes created on address basis. In message box list, the assigned users or a number of messages left , HDD usage can be verified and the box provides management (initialize, move and delete) for each address of the mail boxes. AddPac Technology...
  • Page 86 Unassigned address searches and references the address list without the message box created, and creates the message boxes collectively. Ref. Description Create Selected Create the message boxes for the Message Boxes selected address collectively Refresh Refresh the unassigned address list AddPac Technology...
  • Page 87 Choose the option for partition (optional) ⑥ Choose the type of audio codec ⑦ Set the number of frame for each packet ⑧ Choose the option for enabling the IVR service ⑩ ⑨ Go to IVR Schedule mode AddPac Technology...
  • Page 88 Configure the days of the registered schedule Configure the starting and ending time of the registered schedule ④ The basic IVR scenario of the corresponding Service Number Set the priority level for the service of the registered schedule ⑤ ⑥ ⑦ AddPac Technology...
  • Page 89 1) Creating a NewProject shows the New Project window for the setting of each property. Click ‘OK’, then the scenario ID with the same directory under the specified path is created and well as the basic Project within. AddPac Technology...
  • Page 90 Example of Smart IVR Editor Add ‘Get Number menu’ You can also create the diagram as to drag and drop from the Diagram Tool Box. AddPac Technology...
  • Page 91 Each Diagram needs to be connected to display the order and branch conditions. All the Diagrams can have more than one connection. Depending on the types of diagram, many braches can be connected. Connecting each Diagram can be processed in the following procedure: AddPac Technology...
  • Page 92 Event Condition Set the branch condition for occurrence of the Event by the user’s input. OK is for receiving the input normally, the Event Digit is for receiving the Event Digit value. For more details of the branch condition, please refer to the branch condition of the Menu Diagram AddPac Technology...
  • Page 93 Example of Smart IVR Editor 5) Add ‘Processing’ and two ‘play’ menu with make link AddPac Technology...
  • Page 94 Example of Smart IVR Editor 5) Add more menus which connect with high level AddPac Technology...
  • Page 95 Example of Smart IVR Editor 5) Add more menus which connect with high level AddPac Technology...
  • Page 96 Example of Smart IVR Editor 5) Add more menus which connect with high level AddPac Technology...
  • Page 97 Example of Smart IVR Editor 6) Add more menus which connect with high level AddPac Technology...
  • Page 98 Example of Smart IVR Editor 6) Add more menus which connect with high level AddPac Technology...
  • Page 99 When the Project Build is finished, a message of success is displayed as it is shown Set Connection Configuration Set server information - Server IP(IPNext) - FTP information (User ID: root / Password : router) - Http information (User ID: root / Password : router) - check Use Authorization AddPac Technology...
  • Page 100 When the Project Transfer window opens as it is shown in below, set the Upload from the Transfer type and then click OK. You may see the window opens up for 3 types of Codec format to be selected. when uploading the Project is completed. AddPac Technology...
  • Page 101 Appendix • IPNext (Initialize Ldap (SMT)) AddPac Technology...
  • Page 102 1. Main page for maintenance tool Click to “Next” 2. Set the IPNext’s IP address to system host field Don’t need to change Port and user ID (if you change IPNext’s http port it need to set same port) AddPac Technology...
  • Page 103 Initialize Ldap (SMT) 1. Display IPNext 700’s information 2. Choose System recovery 3. Choose System initialize 4. Select Full initialize System Maintenance tools Cont. AddPac Technology...
  • Page 104 Installation guide for IPNext 2. If you already using IPPBX function, all IPPBX function be stop 1. Display which function will do. 3. Stop all IPPBX function with restore all data to IPPBX System Maintenance tools Cont. AddPac Technology...
  • Page 105 Installation guide for IPNext 2. Show all System initialize completed ”Click OK” 1. After System initialize it need to reboot “Click OK” 3. Display System initialize completed “ Click Exit” System Maintenance tools Cont. AddPac Technology...
  • Page 106 IPNext Stand alone Test 2. PC will download SMM automatically when click icon. 1. Access IPNext via web-browser http://172.17.109.200:80 3. after download it’ll display login page login ID : root password : router AddPac Technology...
  • Page 107 IPNext Stand alone Test After login Web SMM Stand alone Simple Test Scenario. 1.Add 2~3 user datas.. 2.Add 2~3 tel numbers. 3.Register 2~3 terminals. 4.Make a call each other. 5.Make backup file.(excel or ldap) 6.Add more information. AddPac Technology...

  • Page 108: Thank You

    Thank you AddPac Technology...
