IPNext 190 System Installation Guide
Chapter 5.

Console Port Signal and Pinout

This Appendix describes the pinout specification of the following cables used for AddPac IP-
PBX:
Console port signals and pinout (RJ-45 to DB9)
Pinout of UTP cable assembly (RJ-45 to RJ-45)
The built-in RJ-45 to DB9 (Female DTE Connector) cable is used to connect the console port
of the Ipnext190 system with the PC where the terminal emulation software operates.
Console Port
Appendix

Table 5-1 Console Port Pinout

RJ-45
(DTE)
Signal RJ-45 Pin
RTS
DTR
TxD
GND
GND
RxD
DSR
CTS
AddPac Technology Proprietary & Documentation
DB-9
DB-9 Pin
1 8
2 6
3 2
4 5
5 5
6 3
7 4
8 7
Console
Device
(PC)
Signal
CTS
DSR
RxD
GND
GND
TxD
DTR
RTS
