IPNext 190 System Installation Guide
Installing
Connecting Async Serial interface
Connect RJ-45 type of RS-232C Serial Console Cable to the console port. Then connect the serial
connector to the serial port of the PC management on the other side.
Figure 2-1 Connecting Async Serial Interface
AddPac Technology Proprietary & Documentation
RJ45 to DB9
Console Cable
Management
PC
132 - 30
