Adding a DLC Operator Position

If you are adding a line/trunk, call AT&T 1 800 247-7000 to arrange for an
AT&T technician to connect the line to the system and set it up. If you are
removing a line, it is not necessary to make any such arrangements.
NOTE:
A new module must be installed before a line is connected to it.
After the line is connected and set up or is disconnected, open the
System Programming menu from the console or a PC with SPM to
program it as described in the next task.
Assign the line to or unassign the line from a pool, to/from extensions (if
it's a personal line), to/from a calling group, or to/from Remote Access, as
appropriate, following the instructions in the "Telephones" section of
Chapter 3 in System Programming .
Revise the appropriate planning form(s).
When you have finished, file the form(s) with the rest of the planning
forms.
Programming Instructions
See the appropriate procedures in System Programming as noted in the task list
above.
Adding a DLC Operator Position
Use this procedure to add a DLC operator position to either an MLX or an
analog multiline extension module.
To add a QCC operator position, see the next section, "Adding a QCC Operator
Position."
Planning Guidelines
DLC operator positions can be assigned to the first and fifth extension jacks on
any MLX or analog multiline module. The first jack on the first extension module
in your system is automatically assigned as the primary operator position.
If your system has Call Management System (CMS), the two CMS connections
must be made to analog jacks. Each CMS requires two DLC operator positions
on the same analog module to connect the equipment and one position to serve
as CMS supervisor.
