Configuring Type Network QoS Policies

Step 3
Step 4
Step 5
Configuring Type Network QoS Policies
Type network qos policies can only be configured on the system qos attachment point. They are applied to
the entire switch for a particular class.
Procedure
Step 1
Step 2
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
438
Command or Action
switch(config)# no policy-map
[type {network-qos | qos |
queuing}] policy-name
switch(config-pmap)# class [type
{network-qos | qos | queuing}]
class-name
switch(config-pmap)# no class
[type {network-qos | qos |
queuing}] class-name
Command or Action
switch# configure terminal
switch(config)# policy-map type
network-qos policy-name
Purpose
The three policy-map configuration modes are as follows:
• network-qos—Network-wide (global) mode. CLI prompt:
switch(config-pmap-nq)#
• qos—Classification mode; this is the default mode. CLI
prompt: switch(config-pmap-qos)#
• queuing—Queuing mode. CLI prompt:
switch(config-pmap-que)#
(Optional)
Deletes the specified policy map.
Associates a class map with the policy map, and enters
configuration mode for the specified system class. The three
class-map configuration modes are as follows:
• network-qos—Network-wide (global) mode. CLI prompt:
switch(config-pmap-c-nq)#
• qos—Classification mode; this is the default mode. CLI
prompt: switch(config-pmap-c-qos)#
• queuing—Queuing mode. CLI prompt:
switch(config-pmap-c-que)#
The associated class map must be the same type as
Note
the policy-map type.
(Optional)
Deletes the class map association.
Purpose
Enters configuration mode.
Creates a named object that represents a set of policies that
are to be applied to a set of traffic classes. Policy-map names
can contain alphabetic, hyphen, or underscore characters, are
case sensitive, and can be up to 40 characters.
Configuring System Classes
OL-16597-01
