SPAN Destinations

• Cannot be a destination port.
• Each source port can be configured with a direction (ingress, egress, or both) to monitor. For VLAN,
• Source ports can be in the same or different VLANs or VSANs.
• For VLAN or VSAN SPAN sources, all active ports in the source VLAN or VSAN are included as
• The switch supports a maximum of two egress SPAN source ports.
SPAN Destinations
SPAN destinations refer to the interfaces that monitors source ports. The Cisco Nexus 5000 Series switch
supports Ethernet and Fibre Channel interfaces as SPAN destinations.
Source SPAN
Ethernet
Fibre Channel
Fibre Channel
Virtual Fibre Channel
Virtual Fibre Channel

Characteristics of Destination Ports

Each local SPAN session must have a destination port (also called a monitoring port) that receives a copy of
traffic from the source ports, VLANs, or VSANs. A destination port has these characteristics:
• Can be any physical port, Ethernet, Ethernet (FCoE), or Fibre Channel, and virtual Fibre Channel ports
• Cannot be a source port.
• Cannot be a port channel or SAN port channel group.
• Does not participate in spanning tree while the SPAN session is active.
• Is excluded from the source list and is not monitored if it belongs to a source VLAN of any SPAN
• Receives copies of sent and received traffic for all monitored source ports. If a destination port is
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
674
VSAN, port channel, and SAN port channel sources, the monitored direction can only be ingress and
applies to all physical ports in the group. The rx/tx option is not available for VLAN or VSAN SPAN
sessions.
source ports.
cannot be destination ports.
session.
oversubscribed, it can become congested. This congestion can affect traffic forwarding on one or more
of the source ports.
Dest SPAN
Ethernet
Fibre Channel
Ethernet (FCoE)
Fibre Channel
Ethernet (FCoE)
Configuring SPAN
