Managing FLOGI, Name Server, FDMI, and RSCN Databases

About Name Server Database Entries

The name server stores name entries for all hosts in the FCNS database. The name server permits an Nx port
to register attributes during a PLOGI (to the name server) to obtain attributes of other hosts. These attributes
are deregistered when the Nx port logs out either explicitly or implicitly.
In a multiswitch fabric configuration, the name server instances running on each switch shares information
in a distributed database. One instance of the name server process runs on each switch.

Displaying Name Server Database Entries

The following example shows how to display the name server database for all VSANs:
switch# show fcns database
--------------------------------------------------------------------------
FCID
--------------------------------------------------------------------------
0x010000
0x010001
0x010002
0x010100
0x020000
0x020100
0x020200
The following example shows how to display the name server database and statistical information for a
specified VSAN:
switch# show fcns database vsan 1
VSAN 1:
--------------------------------------------------------------------------
FCID
--------------------------------------------------------------------------
0x030001
0x030101
0x030200
0xec0001
Total number of entries = 4
The following example shows how to display the name server database details for all VSANs:
switch# show fcns database detail
The following example shows how to display the name server database statistics for all VSANs:
switch# show fcns statistics

FDMI

Cisco Nexus 5000 Series switches provide support for the Fabric-Device Management Interface (FDMI)
functionality, as described in the FC-GS-4 standard. FDMI enables management of devices such as Fibre
Channel host bus adapters (HBAs) through in-band communications. This addition complements the existing
Fibre Channel name server and management server functions.
Using the FDMI functionality, the switch software can extract the following management information about
attached HBAs and host operating systems without installing proprietary host agents:
• Manufacturer, model, and serial number
• Node name and node symbolic name
• Hardware, driver, and firmware versions
OL-16597-01
TYPE PWWN
N 50:06:0b:00:00:10:a7:80
N 10:00:00:05:30:00:24:63 (Cisco)
N 50:06:04:82:c3:a0:98:52 (Company 1)
N 21:00:00:e0:8b:02:99:36 (Company A)
N 21:00:00:e0:8b:08:4b:20 (Company A)
N 10:00:00:05:30:00:24:23 (Cisco)
N 21:01:00:e0:8b:22:99:36 (Company A)
TYPE PWWN
N 10:00:00:05:30:00:25:a3 (Cisco)
NL 10:00:00:00:77:99:60:2c (Interphase)
N 10:00:00:49:c9:28:c7:01
NL 21:00:00:20:37:a6:be:14 (Seagate)
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
About Name Server Database Entries
(VENDOR) FC4-TYPE:FEATURE
scsi-fcp fc-gs
ipfc
scsi-fcp 250
scsi-fcp
ipfc
scsi-fcp
(VENDOR) FC4-TYPE:FEATURE
ipfc
scsi-fcp
595
