Configuring MST
Step 3
Step 4

Specifying the MST Name

You configure a region name on the bridge. For two or more bridges to be in the same MST region, they must
have the identical MST name, VLAN-to-instance mapping, and MST revision number.
Procedure
Step 1
Step 2
Step 3
This example shows how to set the name of the MST region:
switch# configure terminal
switch(config)# spanning-tree mst configuration
switch(config-mst)# name accounting

Specifying the MST Configuration Revision Number

You configure the revision number on the bridge. For two or more bridges to be in the same MST region,
they must have the identical MST name, VLAN-to-instance mapping, and MST revision number.
OL-16597-01
Command or Action
switch(config-mst)# exit or
switch(config-mst)# abort
switch(config)# no
spanning-tree mst
configuration
Command or Action
switch# configure terminal
switch(config)# spanning-tree mst
configuration
switch(config-mst)# name name
Purpose
• The first form commits all the changes and exits MST
configuration mode.
• The second form exits the MST configuration mode
without committing any of the changes.
(Optional)
Returns the MST region configuration to the following default
values:
• The region name is an empty string.
• No VLANs are mapped to any MST instance (all VLANs
are mapped to the CIST instance).
• The revision number is 0.
Purpose
Enters configuration mode.
Enters MST configuration submode.
Specifies the name for MST region. The name string
has a maximum length of 32 characters and is
case-sensitive. The default is an empty string.
Cisco Nexus 5000 Series Switch CLI Software Configuration Guide
Specifying the MST Name
185
