6.1

Data Rates Limits

6.1.1 Non-EBEM Modes

Modulation
BPSK
BPSK
BPSK
BPSK
BPSK
BPSK
QPSK
QPSK
QPSK
QPSK
QPSK
QPSK
OQPSK
OQPSK
OQPSK
OQPSK
OQPSK
8PSK
8PSK
8PSK
8QAM
8QAM
8QAM
16QAM
16QAM
Technical Specifications
Chapter 6. Technical
Non-EBEM Modes
Code Rate Min Data Rate (Kbps)
Uncoded
5/16
21/44
1/2
3/4
7/8
Uncoded
21/44
1/2
2/3
3/4
7/8
21/44
1/2
2/3
3/4
7/8
2/3
3/4
7/8
2/3
3/4
7/8
3/4
7/8
6–1
DMD1050TS Satellite Modem Board
Specifications
Max Data Rate (Mbps)
4.8
2.4
2.4
2.4
3.6
4.2
9.6
4.8
4.8
6.4
7.2
8.4
4.8
4.8
6.4
7.2
8.4
9.6
10.8
14.4
9.6
10.8
14.4
14.4
16.84
Revision 1
10.0
3.125
4.773
5.0
7.5
8.75
20.0
9.545
10.0
13.333
15.0
17.5
9.545
10.0
13.333
15.0
17.5
20.0
20.0
20.0
20.0
20.0
20.0
20.0
20.0
