Step
10
(cont)
In the event that an error occurs during the Image Upgrade Process, then a message stating that an error
occurred will appear.
For troubleshooting purposes, three common reasons for disruption of the Firmware Application Process are:
Power Failure;
•
Loss of Ethernet signal (e.g., disconnection of Ethernet cable);
•
Attempting to load firmware other than the TRANSEC Module bulk firmware (i.e., FW-0020567x.bin).
Upon successful completion of transfer, the progress bar shows 100%.
11
On the Firmware page, verify that the newly-uploaded firmware is reported in the proper Security
Module Bulk Info slot. If not, update the Active Boot Slot Configuration by using the drop-down menu
to select Newest to force the TRANSEC Module to boot using the firmware with the most recent build date.
Click Submit when done.
12
Click Reboot to boot the TRANSEC Module with the new firmware.
The modem will reboot with the new firmware.
It will be necessary to restart the DMD1050TS TRANSEC Module HTTPS Interface session once the modem
has returned online.
13
To load the second image, repeat Steps 9 through 11.
TRANSEC Module HTTPS Interface
Any power failure during this process will result in failure of the
TRANSEC Module.
DMD1050TS Satellite Modem Board
Task
8–19
Revision 1
MN-DMD1050TS
