7.7.1.6
Transmit | ITA Page
Transmit | ITA Page
ITA Control
Waveform Mask
Properties
Highlighted
Waveform Mask
Indicate the
Following
Web Browser
Figure 7-17. Transmit | ITA Page Example
DISABLED
•
ENABLED
•
BPSK
•
o
1/2
o
2/3
o
3/4
o
7/8
o
19/20
QPSK
•
o
1/2
o
2/3
o
3/4
o
7/8
o
19/20
8-PSK
•
o
1/2
o
2/3
o
3/4
o
7/8
o
19/20
16-APSK
•
o
1/2
o
2/3
o
3/4
o
7/8
o
19/20
Unattainable
•
Attainable
•
Current
•
7–29
DMD1050TS Satellite Modem Board
Enable or disable the ITA function.
Use to select the mod/code rate.
Displays the status of each waveform when ITA is engaged.
Only available in EBEM mode.
