7.7.6.2 Test | I/Q Plot Page
The I/Q Plot page shows the RX I/Q sampled data as seen by the receiver.
Test | I/Q Plot Page
PICK A COLOR
START
STOP
Web Browser
Figure 7-39. Test | I/Q Plot Page Example
RED
•
GREEN
•
7–71
DMD1050TS Satellite Modem Board
Click START to run the I/Q Plot.
Click STOP to end the I/Q Plot.
