DMD1050TS Satellite Modem Board
Revision 1
J3
Pin 1
J3 J2 J6 J1
BUC & LNB SMA COMPACT SMA
INPUT POWER OPT (F) FLASH CARD OPT (F)
RX L-BAND TX L-BAND

Figure 4-1. DMD1050TS Front View

Figure 4-2. DMD1050TS Rear View

Rear Panel Interface 4–2 MN-DMD1050TS
