Comtech EF Data DMD1050TS Installation And Operation Manual page 131

IP Administration | Modem Addressing
Boot Mode
IP Address Mask
Modem IP Address
Router IP Address
Trap Agent IP
Address
Click Save (or Cancel).
Web Browser
DEFAULT: During initialization (boot up), the modem will restore the
DEFAULT
web setting to the standard IP Mask and addresses supplied by the
NON-VOL
modem. The modem will be taken off the network and will not be
BOOTP
accessible. The Default settings are:
IP TEST
IP Address Mask:
Modem IP Address:
Server IP Address:
Router IP Address:
NON-VOL: Stores and uses IP Mask and addresses as provided by
the user.
BOOTP: During initialization (boot up), the modem will get the
names, masks, and IP Addresses of the modem, router, and server.
IP TEST: The IP Test boot mode has a behavior similar to the default
boot mode. The Terminal, IP, SNMP, FTP and Web parameters
changed by the default setting are reset by the IP Test boot more as
well. It stores and uses IP Mask and addresses to fixed settings as
listed below.
Bootp Server Tag:
IP Address Mask:
Modem IP Address:
Server IP Address:
Router IP Address:
XXX.XXX.XXX.XXX The IP Address Mask of the local network is expressed in a
hexadecimal format, and must be a valid TCP/IP Mask. This field
should be set before changes are made to the Modem or Router
Address.
XXX.XXX.XXX.XXX The IP Address of the modem must be consistent for the mask
defined. This address is expressed in hexadecimal format.
Broadcast and loop back addresses are not allowed. These are
addresses with all subnet bits set to 0's or 1's.
XXX.XXX.XXX.XXX The IP Address of the Local Network Router. If a router is present on
the local network, this address must be consistent with the IP Mask
and the subnet of the modem. If no router is present, then the
address must be set to a foreign address. This address is expressed
in hexadecimal format. Broadcast and loop back addresses are not
allowed. These are addresses with all subnet bits set to 0's or 1's.
XXX.XXX.XXX.XXX IP address of the device receiving SNMP Traps
Hexadecimal Mask
{ddd.ddd.ddd.ddd}
Decimal Mask
7–9
DMD1050TS Satellite Modem Board
255.000.000.000 (FF.00.00.00 hex)
010.000.000.001 (C0.A8.00.EE hex)
010.001.001.001 (0A.01.01.01 hex)
010.000.001.001 (0A.00.01.01 hex)
206
255.255.255.000 (FF.FF.FF.00 hex)
192.168.0.238 (C0.A8.00.EE)
192.168.000.101 (C0.A8.00.65)
192.168.000.102 (C0.A8.00.66)
MN-DMD1050TS
Revision 1
