8.4.2.2 Transmit Status
Item
TX Frame Count
TX Status
DCM Lock
Bypass Traffic
Crypto Traffic
8.4.2.3 Receive Status
Item
RX CRC Errors
RX Frame Count
RX Status
DCM Lock
Unique Word Lock
Out of Sync
8.4.2.4 Automatic Refresh Status Timer
The page updates itself automatically for the duration of the countdown timer. When the timer
reaches 0:00, the page will stop updating to help conserve system resources.
To manually override the timer, click Stop to interrupt or Reset to restart the timer.
TRANSEC Module HTTPS Interface
Displays the number of transmitted AES 256 frames.
Describes the value of the Tx Status register.
Displays the state of the Tx DCM lock.
Displays the encryption status (Bypass on means Encryption off).
When Detected, the module has sampled outgoing traffic and verifies it has been
encrypted. When Not Detected, encryption is off, or the module cannot verify
encrypted traffic.
Displays the count of received CRC errors.
Displays the number of received AES 256 frames.
Displays the value of the Rx Status register.
Displays the state of the Rx DCM lock.
Indicates that the decryption engine has successfully found the unique word and has
been able to lock to it.
Indicates that an out-of-sync condition has been detected by the encryption engine.
