Comtech EF Data DMD1050TS Installation And Operation Manual page 192

Test | Pattern / Carrier Page
Loopback Type
Pattern Ber
Pattern Error Count
Carrier Type
RESTART TEST
PATTERN
Web Browser
NONE
•
TERR RX
•
BASEBAND RX
•
TERR TX
•
BASEBAND TX
•
IFEC TX
•
IF
•
TERR TX/RX
•
BASEBAND TX/RX
•
NO SYNC
•
nnnn x 10
-n
•
NO SYNC
•
nnnn x 10
n
•
NORMAL
•
CW
•
DUAL
•
OFFSET
•
POS FIR
•
NEG FIR
•
7–70
DMD1050TS Satellite Modem Board
This shows the measured Bit Error Rate for the received
test pattern.
This shows the number of errors detected by the test
pattern checker.
Use to reset the test pattern counter and generator.
