6.9.16 BER Performance 16APSK (MILSTD 188-165B or STANAG)
Turbo
1E-1
Specification
1E-2
1E-3
1E-4
1E-5
1E-6
1E-7
1E-8
1E-9
0 1

Figure 6-16. BER Performance 16APSK (MILSTD 188-165B or STANAG)

Note: Eb/No to Bit-Error-Ratio 77 values based on 16k block size
Technical Specifications
1/2 Rate
Specification
2/3 Rate
Typical
Performance
2 3 4
DMD1050TS Satellite Modem Board
16QAM Uncoded Theory
Specification
3/4 Rate
Specification
7/8 Rate
5 6 7 8
Eb/No in dB
6–24
Revision 1
MILSTD 188-165B
or STANAG
Decoder
Specification
19/20 Rate
9 10 11 12
MN-DMD1050TS
