Comtech EF Data DMD1050TS Installation And Operation Manual page 142

Transmit | Data Page
Satellite Framing
Terrestrial Framing
Data Polarity
Symbol Pair
ESC Overhead
Async Inband Rate
SCC Inband Rate
SCC Control Ratio
EBEM Ethernet Rate
Web Browser
NONE
•
IDR 96K
•
IBS 1/15
•
ASYNC 1/15
•
EF AUPC
•
EDMAC
•
SCC
•
EFFICIENT D&I
•
(optional)
DVB
•
EBEM
•
NONE
•
188
•
204
•
INVERT NONE
•
INV. TERR DATA
•
INV. BASEBAND
•
INV. TERR&BASE
•
NONE
•
NORMAL
•
SWAPPED
•
VOICE X2
•
DATA 64KBPS
•
75
•
150
•
300
•
600
•
1200
•
2400
•
4800
•
9600
•
19200
•
38400
•
57600
•
115200
•
300 to 200000
•
3000 to 115200 (when
•
using SCC Framing)
1:1
•
1:2
•
1:3
•
1:4
•
1:5
•
1:6
•
1:7
•
XXXXXXXXX
7–20
DMD1050TS Satellite Modem Board
Use to select the framing type.
This is used only with IDR, IBS or Asynchronous Interface.
DVB Only
Use to invert the Tx Data polarity.
Use to swap the I & Q Channels. BPSK Mode Only.
IDR ESC Channel used for Voice or 64 K data channel.
Use to select the Async Inband Rate.
Use to request the rate of in-band data for the overhead
channel. This is available only when Tx Satellite Framing
is set to SCC.
Use to simulate the framing used by the Satellite Control
Channel Option (Pass Thru Mode only).
The SCC Control Ratio is the ratio of overhead in-band
data to synchronizing words.
This is available only when Tx Satellite Framing is set to
SCC.
Future option.
Revision 1
MN-DMD1050TS
