Appendix E. User Interface
E.1

User Interface Connections

Supplied mating connectors can be used, but are not required.
E.2

Connector Kit part numbers

CEFD P/N
1. CA/3446-9
2. CONN0003-040
3. CNR102387-1
4. CNR102387-6
5. TMR102548-6
6. CN/MOL04F12
7. TM/CPF08
E.2.1 J3 & J4 Interface Connectors located on PCB
•
J3: Async Interface Connector - 10Pin Dual Row: Mfg (Samtec) P/N: TSW-1-05-7-G-D
•
J4: Mil 188-114A Connector - 26Pin Dual Row: Mfg (Samtec) P/N: TSW-1-13-7-G-D
•
MFG: Samtec connector information
o
o
o
o
Style
-07
o
o
E.2.2 J3 & J4 Information on Supplied Interface Connectors
J3
J4
J16
Appendix E
MIL-STD-188-114A
Shorting/default plug
Dual Row header 10 Pin
Dual Row Header 26 Pin
Receptacle Contacts
Conn Crimp 4 Terminal Housing
Terminal crimp 18-24AWG for 2139
TSW = Terminal strip series
-1 = .100" Centers
05 or 13 = Number of pins per row
7 = Straight pin version dimensions
A
.100
G = Gold plating
D = Dual Row.
Async Interface
Mil 188-114A
Receptacle Contacts
Connections
Description
Dimensions (inches)
B
0.430
10Pin Dual Row:
26Pin Dual Row:
E–1
DMD1050TS Satellite Modem Board
Revision 1
Connector Location
J4
JP1 & JP2
J3
J4
J3 & J4
J3 & J16
J3 & J16
C
0.430
Mfg (Tyco) P/N: 102387-1
Mfg (Tyco) P/N: 102548-6
Mfg (Tyco) P/N: 1-87309-4
