Comtech EF Data DMD1050TS Installation And Operation Manual page 158

Receive | Data Page
SCC Control Ratio
EBEM Ethernet Rate
EBEM Embedded
Channel
EBEM Overhead
Rate
EBEM Encryption
Web Browser
1:1
•
1:2
•
1:3
•
1:4
•
1:5
•
1:6
•
1:7
•
XXXXXXXXX
DISABLE
•
ENABLE
•
OFF
•
8K
•
16K
•
24K
•
32K
•
40K
•
48K
•
56K
•
64K
•
DISABLE
•
ENABLE
•
7–36
DMD1050TS Satellite Modem Board
This is available only when SCC is selected for the Rx
Satellite Framing.
Use to simulate the framing used by the Satellite Control
Channel option (Pass Thru Mode only). The SCC CTL
RATIO is the ratio of overhead in-band data to
synchronizing words.
Future option.
Future option.
Enable or disable the embedded overhead channel.
Future option.
Use to select the overhead channel bandwidth.
Future option.
Use to encrypt the transmit data. This is available when a
FIPs Module is installed on the DMD1050TS and the transit
FEC is either TPC or LDPC.
