Appendix I
Table I-9. ITA Waveform Masks (Reference Demodulator)
DMD1050TS Menu Settings (Reference)
Menu Option
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
ITA
DMD1050TS Satellite Modem Board
Parameter
BPSK 1/2
BPSK 2/3
BPSK 3/4
BPSK 7/8
BPSK 19/20
QPSK 1/2
QPSK 2/3
QPSK 3/4
QPSK 7/8
QPSK 19/20
8PSK 1/2
8PSK 2/3
8PSK 3/4
8PSK 7/8
8PSK 19/20
16APSK 1/2
16APSK 2/3
16APSK 3/4
16APSK 7/8
16APSK 19/20
I–12
Revision 1
Value
NOT SELECTSED
SELECTED
NOT SELECTSED
NOT SELECTSED
NOT SELECTSED
NOT SELECTSED
SELECTED
NOT SELECTSED
NOT SELECTSED
NOT SELECTSED
NOT SELECTSED
NOT SELECTSED
SELECTED
NOT SELECTSED
NOT SELECTSED
SELECTED
NOT SELECTSED
NOT SELECTSED
SELECTED
SELECTED
MN-DMD1050TS
