SNMP VERSION: V1 & V2
TRAP VERSION: V1
AUTHORIZATION: TRAPS OFF
RD COMMUNITY: PUBLIC
RDWR COMMUNITY: PUBLIC
USER 1
Viewer-md5
ACCESS GROUP
VIEWER
AUTH PASSWORD
Viewer
PRIV PASSWORD
Viewer
AUTHENTICATION
MD5
PRIVACY
DES
WEB MENU
Confirmation
User 1
User 2
User 3
Web Browser

Table 7-2. SNMP Parameters

USER 2
Viewer-sha
ACCESS GROUP
VIEWER
AUTH PASSWORD
Viewer
PRIV PASSWORD
Viewer
AUTHENTICATION
SHA
PRIVACY
DES

Table 7-3. Web Parameters

ENABLED
•
DISABLED
•
Access Group NO GROUP
•
GUEST
•
OPER
•
ADMIN
•
Authorization
xxxxxxxx
Password
User Reset
7–12
DMD1050TS Satellite Modem Board
USER 3 USER 4
Oper-md5 Oper-sha
ACCESS GROUP ACCESS GROUP
OPER OPER
AUTH PASSWORD AUTH PASSWORD
Oper Oper
PRIV PASSWORD PRIV PASSWORD
Oper Oper
AUTHENTICATION AUTHENTICATION SHA
MD5
PRIVACY PRIVACY
DES DES
Enable or disable a confirmation response if a
change is made to the modem output.
NO GROUP: Denies all access.
GUEST: Guests can access most of the site to
see modem parameters.
OPER: Operators can monitor and control
parameter settings, and change their own
authentication passwords.
ADMIN: Administrators can monitor and control
the parameters, change any user's name and
authentication password, and modify IP network
settings. ADMIN setting gives access to the entire
site.
User to select password. The user can modify the
Authorization Passwords. The user name can have
up to 14 characters supporting alpha and numeric
characters. Alpha characters can be entered using
the up and down arrow keys. Numeric characters
can be selected by using the number keys on the
front panel. The user can clear all characters from
the front panel screen.
Resets group and password.
