Em Dp01 Profibus Dp Module - Siemens SIMATIC S7 System Manual

A.10

EM DP01 PROFIBUS DP module

Table A- 155 General specifications
Technical data
Article number
Dimensions W x H x D (mm)
Weight
Power dissipation
V DC requirements
+5 V DC (SM Bus)
+24 V DC
Table A- 156 EM features
Technical data
Number of ports (limited pow-
er)
Electrical interface
PROFIBUS DP / MPI baud
rates (set automatically)
Protocols
Cable length
Up to 93.7 Kbps
187.5 Kbps
500 Kbps
1 to 1.5 Mbps
3 to 12 Mbps
Network capabilities
Station address settings
Maximum stations per seg-
ment
Maximum stations per net-
work
MPI connections
S7-200 SMART
System Manual, V2.3, 07/2017, A5E03822230-AF
EM DP01 PROFIBUS DP
6ES7288-7DP01-0AA0
70 x 100 x 81
176.2 g
1.5 W (no load)
150 mA (no load)
See below
EM DP01 PROFIBUS DP module
1
RS485
9.6, 19.2, 45.45, 93.75, 187.5, and 500 Kbps; 1.5, 3, 6, and 12 Mbps
PROFIBUS DP slave and MPI slave
1200 m
1000 m
400 m
200 m
100 m
0 to 99 (set by rotary switches)
32
126, up to 99 EM DP01 stations
6 total (1 reserved for an OP)
Technical specifications
A.10 EM DP01 PROFIBUS DP module
