Technical specifications
A.7 Analog signal boards
Technical data
Isolation (field side to logic)
Cable length (meters)
Table A- 140 Diagnostics
Model
Overflow/underflow
24 V DC low voltage
SB AE01 wiring current transducers
Wiring current transducers are available as 2-wire transducers and 4-wire transducers as
shown below.
Table A- 141 Wiring diagram for the SB AE01 Analog 1 x Input (6ES7288-5AE01-0AA0)
SB AE01 - SB Analog Input 1 x Input (6ES7288-5AE01-0AA0)
768
SB Analog 1 x input (SB AE01)
None
100 m twisted and shielded
SB Analog 1 x input (SB AE01)
Yes
None
①
Connect "R" and "0+" for current applications.
Note: Connectors must be gold. See Appendix F,
Spare parts and other hardware for article num-
ber.
