Technical specifications
A.3 Digital inputs and outputs expansion modules (EMs)
Table A- 81
A.3.3 EM DT16, EM DR16, EM DT32, and EM DR32 digital input/output
specifications
Table A- 82 General specifications
Model
Article number
Dimensions W x H x D (mm)
Weight
Power dissipation
Current consumption (SM Bus)
Current consumption (24 V DC)
732
Connector pin locations for EM QT16 Digital 16 x Outputs Transition (6ES7288-2QT16-
0AA0)
Pin X10
1 No connection
2 DQ a.0
3 DQ a.1
4 DQ a.2
5 DQ a.3
6 DQ a.4
7 DQ a.5
EM Digital
8 x Inputs/
Digital 8 x Outputs
(EM DT16)
6ES7288-2DT16-
0AA0
45 x 100 x 81
179.7g grams
2.5 W
145 mA
4 mA / Input used
11 mA / Relay coil
used
X11
1L / 24 V DC
1M / 24 V DC
Functional Earth
2L / 24 V DC
2M / 24 V DC
DQ a.6
DQ a.7
EM Digital EM Digital
8 x Inputs/ 16 x Inputs/
8 x Relay Outputs Digital 16 x Outputs
(EM DR16) (EM DT32)
6ES7288-2DR16- 6ES7288-2DT32-
0AA0 0AA0
45 x 100 x 81 70 x 100 x 81
201.9 grams 257.3 grams
5.5 W 4.5 W
145 mA 185 mA
4 mA / Input used 4 mA / Input used
11 mA / Relay coil
used
System Manual, V2.3, 07/2017, A5E03822230-AF
X12
4L / 24 V DC No connection
4M / 24 V DC DQ b.2
No connection DQ b.3
3L / 24 V DC DQ b.4
3M / 24 V DC DQ b.5
DQ b.0 DQ b.6
DQ b.1 DQ b.7
EM Digital
16 x Inputs /
16 x Relay Outputs
(EM DR32)
6ES7288-2DR32-
0AA0
70 x 100 x 81
295.4 grams
10 W
180 mA
4 mA / Input used
X13
