Description of the blocks
4.1 Functions for all blocks
Icons
The icons for the Quality Code are displayed in the block icon and in the overview window of
the faceplates.
Table 4- 4
Quality Code
16#80
16#60
16#00
16#28
16#68
16#A4
Active Quality Codes for the
1
status.
Reference
You can obtain further information on the Quality Code display, in the PCS 7 libraries APL
Styleguide programming manual in the Internet
(https://support.industry.siemens.com/cs/document/59062870).
76
Icons for Quality Code display
Symbol
1
1
Trip
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Meaning
Good
Local function check / simulation
Bad, device-specific, value not valid
Bad, process-specific
Uncertain, device-specific
Maintenance demand
, , , and
Intlock Permit Protect
parameters in the interlock
SIMOCODE pro PCS 7 Library V9.0
