Parameter
A.7 Block parameter MMRevDhl
Parameter Data format
Protect STRUCT
•
•
Prot_En BOOL
ProtRev STRUCT
•
•
ProtRevEn BOOL
FFwdForce STRUCT
•
•
FwdForce STRUCT
•
•
StopForce STRUCT
•
•
RevForce STRUCT
•
•
FRevForce STRUCT
•
•
UserAna1 STRUCT
•
•
UA1unit INT
UserAna2 STRUCT
•
•
UA2unit INT
FwdChnST STRUCT
•
•
RevChnST STRUCT
•
•
276
Default setting
–
Value: BOOL 1
•
ST: BYTE 16#FF
•
TRUE
–
Value: BOOL 1
•
ST: BYTE 16#FF
•
TRUE
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: REAL 0.0
•
ST: BYTE 16#80
•
0
–
Value: REAL 0.0
•
ST: BYTE 16#80
•
0
–
Value: BOOL 0
•
ST: BYTE 16#80
•
–
Value: BOOL 0
•
ST: BYTE 16#80
•
Meaning
0 = Protection is active
1 = Protection is not active
0 = Protection disabled
1 = Protection enabled
0 = Protection Rev/FastRev is active
1 = Protection Rev/FastRev is not active
0 = Protection Rev/FastRev disabled
1 = Protection Rev/FastRev enabled
1 = Start: Fast Forward Command in Forced Operation
1 = Start: Forward Start Command in Forced Operation
1 = Stop: Stop Command in Forced Operation
1 = Start: Reverse Start Command in Forced Operation
1 = Start: Fast Reverse Command in Forced Operation
User Analog Input 1
Unit of UserAna1
User Analog Input 2
Unit of UserAna2
Output channel state of Forward
Output channel state of Reverse
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
SIMOCODE pro PCS 7 Library V9.0
