Parameter
A.6 Block parameter MMLog
Parameter Data format
SigMsg6 STRUCT
Value:
•
BOOL
ST: BYTE
•
SigMsg7 STRUCT
Value:
•
BOOL
ST: BYTE
•
SigMsg8 STRUCT
Value:
•
BOOL
ST: BYTE
•
MsgErr1 BOOL
MsgErr2 BOOL
MsgStat1 WORD
MsgStat2 WORD
MsgAckn1 WORD
MsgAckn2 WORD
ErrorNum INT
ReserveOut WORD
Structure of OMODE
Table A- 21
Bytes
Byte 3
Byte 2
Byte 1; 0
272
Default setting Meaning
– Signal Message 6
0
•
16#80
•
– Signal Message 7
0
•
16#80
•
– Signal Message 8
0
•
16#80
•
FALSE 1 = Messaging Error Occurs ALARM_8P1
FALSE 1 = Messaging Error Occurs ALARM_8P2
16#00 ALARM_8P1: Status Output
16#00 ALARM_8P2: Status Output
16#00 ALARM_8P1: ACK_STATE Output
16#00 ALARM_8P2: ACK_STATE Output
1 Error Number
16#00 Reserved
Structure of OMODE – MMLog
Value
16#80: Valid data
16#40: Invalid data
16#20: Redundancy error
16#01: Warm restart (OB100)
16#0000 –
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Meaning
Irrelevant
–
Irrelevant
