Output parameters for SIMOCODE pro PROFINET devices
Table A- 15 MMMeas output parameter for PROFINET devices
Parameter Data format
AM2Out STRUCT
Value: REAL
•
ST: BYTE
•
AM2OutE STRUCT
Value: REAL
•
ST: BYTE
•
AM2In1 STRUCT
Value: REAL
•
ST: BYTE
•
AM2In1E STRUCT
Value: REAL
•
ST: BYTE
•
AM2In2 STRUCT
Value: REAL
•
ST: BYTE
•
AM2In2E STRUCT
Value: REAL
•
ST: BYTE
•
AM2In3 STRUCT
Value: REAL
•
ST: BYTE
•
AM2In3E STRUCT
Value: REAL
•
ST: BYTE
•
MaxTemp2 STRUCT
Value: REAL
•
ST: BYTE
•
TM2Temp1 STRUCT
Value: REAL
•
ST: BYTE
•
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Default setting Meaning
– AM2 Analog Output
0.0
•
16#80
•
– AM2 Analog Output Effective in mA
0.0
•
16#80
•
– AM2 Analog Input 1
0.0
•
16#80
•
– AM2 Analog Input 1 Effective in mA
0.0
•
16#80
•
– AM2 Analog Input 2
0.0
•
16#80
•
– AM2 Analog Input 2 Effective in mA
0.0
•
16#80
•
– AM2 Analog Input 3
0.0
•
16#80
•
– AM2 Analog Input 3 Effective in mA
0.0
•
16#80
•
– TM2 max. temperature in Celsius
0.0
•
16#80
•
– TM2 Temperature 1 in Celsius
0.0
•
16#80
•
Parameter
A.4 Block parameter MMMeas
