Parameter Data format
ExtMsg2 STRUCT
Value: BOOL
•
ST: BYTE
•
ExtMsg3 STRUCT
Value: BOOL
•
ST: BYTE
•
ExtVa105 ANY
ExtVa106 ANY
ExtVa107 ANY
ExtVa108 ANY
ExtVa109 ANY
ExtVa110 ANY
ReserveIn WORD
Output parameters
Table A- 2 Output parameter MMDiag
Parameter Data format
GrpErr STRUCT
Value: BOOL
•
ST: BYTE
•
RackF_Act STRUCT
Value: BOOL
•
ST: BYTE
•
ModF_Act STRUCT
Value: BOOL
•
ST: BYTE
•
Rack1Err STRUCT
Value: BOOL
•
ST: BYTE
•
Rack2Err STRUCT
Value: BOOL
•
ST: BYTE
•
BusFlt BOOL
RdEn BOOL
RdErr STRUCT
Value: BOOL
•
ST: BYTE
•
RdErrStat WORD
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Default setting Meaning
– External Message 2
0
•
16#80
•
– External Message 3
0
•
16#80
•
– External Value 5
– External Value 6
– External Value 7
– External Value 8
– External Value 9
– External Value 10
16#00 Reserved
Default setting Meaning
– 1 = Group error is active
0
•
16#80
•
– 1 = Rack failure
0
•
16#80
•
– 1 = Module Failure
0
•
16#80
•
– 1 = DP slave/IO system failure (primary)
0
•
16#80
•
– 1 = DP slave/IO system failure (redundant)
0
•
16#80
•
FALSE 1 Connection fault
FALSE 1 = Enable read data record
– 1 = Error read record
0
•
16#80
•
16#00 Status of Read record error
Parameter
A.1 MMDiag block parameter
