Parameter
A.2 Structure of UDTs for MMDiag
Element
DMFLWAIT
DMFPRMERR
EMOPNCKT
EMSHRTCKT
Table A- 6 Event diagnostics information for SIMOCODE pro PROFINET devices
Element
NTPCLKSET
NTPCLKSYNC
INIMODRD
INIMODPROG
INIMODDEL
INIMODPROT
MEMMODPROT
INIMODWRPROT
INIMODIDPROT
TM2WRNHI
TM2TRPHI
TM2SNRERR
TM2OUTRNG
AM2WRNGHI
AM2WRNGLO
AM2TRPHI
AM2TRPLO
LIMIT5
LIMIT6
AM2OPNCKT
SMCWRNG – warning
Table A- 7 Warning diagnostics information for SIMOCODE pro devices
Element
IMUMOVLOPRN
IMUMUNBAL
IMUMOVL
OVLPHSFAIL
INTGNDFLT
240
Data format Meaning
BOOL DM-FL waiting for start-up test
BOOL DM-F incorrect PROFIsafe address or incorrect PROFIsafe
parameter
BOOL EM open circuit
BOOL EM short circuit
Data format Meaning
BOOL NTP clock set
BOOL NTP clock synchronized
BOOL Initialization module read in
BOOL Initialization module programmed
BOOL Initialization module erased
BOOL Initialization module write-protected, parameter changes not
allowed
BOOL Memory module write-protected
BOOL Initialization module write-protected
BOOL Initialization module identification data write-protected
BOOL TM2 warning level T>
BOOL TM2 trip level T>
BOOL TM2 sensor fault
BOOL TM2 out of range
BOOL AM2 warning level 0/4–20 mA>
BOOL AM2 warning level 0/4–20 mA<
BOOL AM2 trip level 0/4–20 mA>
BOOL AM2 trip level 0/4–20 mA<
BOOL Limit Monitor 5
BOOL Limit Monitor 6
BOOL AM2 open circuit
Data format Meaning
BOOL Pre-warning overloaded
BOOL Unbalance
BOOL Overload
BOOL Overload and loss of phase
BOOL Internal earth fault
