DiagTrp1, DiagTrp2 – Trip diagnostics
Table 4- 50 DiagTrp1 – Trip diagnostics for SIMOCODE pro devices
Bit Meaning
0 Hardware fault basic unit
1 Module fault
2 Temporary components
3 Configuration fault
4 Parameterization
5 Bus
6 PLC/DCS
7 Execution on-command
8 Execution stop-command
9 Feedback On
10 Feedback Off
11 Stalled positioner
12 Double 0
13 Double 1
14 End position
15 Antivalence
16 Test position feedback (TPF)
17 Power failure (UVO)
18 Operational protection Off (OPO)
19 Unbalance
20 Overload
21 Overload and loss of phase
22 Internal earth fault
23 External earth fault
24 Thermistor trip level
25 Thermistor short circuit
26 Thermistor open circuit
27 TM1 level T >
28 TM1 sensor fault
29 TM1 out of range
30 Level I >
31 Level I <
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Description of the blocks
4.3 MMOprtn block
139
