Parameter
A.5 Block parameter MMStat
Block parameters
ExtVa104
ExtVa105
ExtVa106
ExtVa107
ExtVa108
ExtVa109
ExtVa110
OS_Perm
OpSt_In
Feature
ReserveIn
Output parameters
Table A- 17 Output parameter MMStat
Parameter
RackF_Act
ModF_Act
GrpErr
RdErr
WrErr
RdErrStat
WrErrStat
262
Data format Default setting
ANY –
ANY –
ANY –
ANY –
ANY –
ANY –
ANY –
STRUCT –
Bit 0: BOOL 1
• •
... 1
• •
Bit 31: BOOL 1
• •
DWORD –
STRUCT –
Bit 0: BOOL 0
• •
... 0
• •
Bit 31: BOOL 0
• •
WORD 16#00
Data format Default setting
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
STRUCT –
Value: BOOL 0
• •
ST: BYTE 16#80
• •
WORD 16#00
WORD 16#00
Meaning
External Value 4
External Value 5
External Value 6
External Value 7
External Value 8
External Value 9
External Value 10
Operator permissions
Enabled operator stations
Status of various features
Reserved
Meaning
1 = Rack Failure
1 = Module Failure
1 = Group error is active
1 = Error read record
1 = Error write record
Status of read record error
Status of Write record error
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
SIMOCODE pro PCS 7 Library V9.0
