Setting the cursor at any random position in the text box is no longer possible in the operator
dialog.
This prevents operating errors by adding decimal points automatically.
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Limits for additional value
"H alarm": Alarm high (
•
"H warning": Warning high (
•
Hysteresis
•
"L warning": Warning low (
•
"L alarm": Alarm low (
•
Curr_WL
If the background color of the field is white, you can change the value in the expanded oper-
ating area in 3 ways (authorization level 5 and higher):
Entry in the input box
•
Setting using the slider
•
Entry by direct operation
•
Last successfull Timestamp of read data
Button for updating the values (
Bar graph for current
The visible range in the bar graph depends on the configuration in the Engineering Station
(ES).
The colored triangles show the specified limits:
Red: Alarm
•
Yellow: Warning
•
Operator control enable
The operator may execute the command.
•
The operator cannot execute the command because the command is currently blocked
•
by a process.
The operator is not permitted to execute the command (
•
The displays are dependent on the bit values in the
ters.
)
Curr_TH
)
Curr_WH
)
Curr_TL
)
).
RdDataOp
OS_PermOut
Description of the blocks
4.3 MMOprtn block
).
OS_Perm
and parame-
OS_PermLog
