Auxiliary variables
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Diag_Evt Event
bit
38 Limit 3
39 Limit 4
40 External fault 1
41 External fault 2
42 External fault 3
43 External fault 4
44 External fault 5
45 External fault 6
46 Analog module open circuit
47 DM-F safety-related tripping
48 DM-F – test required
49 Timestamping active + Ok
50 DM-FL safety Ok
51 DM-F PROFIsafe active
52 Configured operator panel missing
53 Module not supported
54 No module voltage (BU 2)
55 Memory module read in
56 Memory module programmed
57 Memory module erased
58 Addressing plug read in
59 Start-up parameterization block active
60 Parameter changes not allowed in the current operating
states
61 Device does not support the required functions
62 Wrong parameter
63 Wrong password
64 Password protection active
65 Factory settings
66 Parameter assignment active
67 DM-FL configuration mode
68 DM-FL configuration deviation
69 DM-FL waiting for startup test
70 DM FP PRM error
92 EM open circuit
93 EM short circuit
Description of the blocks
4.3 MMOprtn block
