Siemens SIMOCODE pro Programming And Operating Manual page 145

Auxiliary variables
Table 4- 57
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
Diag_Wrn
bit
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
43
44
Bit assignment Diag_Wrn for SIMOCODE pro PROFINET devices
Diag_Wrn 37
38
39
40
41
42
Event
Warning level I>
Warning level I<
Warning level P>
Warning level P<
Warning level cos phi<
Warning level U<
Warning level 0/4–20 mA>
Warning level 0/4–20 mA<
Stalled rotor
No start permitted
Number of starts >
Just one start possible
Motor operating hours >
Stop time >
External fault 1
External fault 2
External fault 3
External fault 4
External fault 5
External fault 6
AM open circuit
DM-F safety-related tripping
DM-F test requirement
DM-F feedback circuit
DM-FL simultaneity
EM open circuit
EM short circuit
TM2 warning T>
TM2 sensor fault
TM2 Out of Range
AM2 Warning 0/4–20 mA>
AM2 Warning 0/4–20 mA<
AM2 open circuit
Description of the blocks
4.3 MMOprtn block
145
