Parameter settings
SIMOCODE pro requires that some parameters have specific settings to ensure correct
operation of the signal blocks:
● Parameters that define the assignment of the cyclic I/O interface. These parameters are
shown in
● Parameters that are already preset in the templates for application selection in
SIMOCODE ES for the control function (*).
General settings (valid for all control functions)
Device parameters → Bus parameters
Diagnosis triggered by device fault
Diagnosis triggered by process faults
Diagnosis triggered by process warnings Active
* Diagnosis triggered by process mes-
sages
Startup parameter block
Standard functions → Test/reset
Test 1
Reset 1
Emergency start
The settings are a suggestion. They depend on the actual wiring of the SIMOCODE pro
inputs and outputs.
Settings for other parameters are required, for example, for motor protection. These are not
described here.
SIMOCODE pro PCS 7 Library V9.0
Programming and Operating Manual, 06/2017, A5E40899442002A/RS-AA/001
italics
in the following overview.
Active
Active
Not active
Active
Cyclic receive bit 0.3
Cyclic receive bit 0.6
Cyclic receive bit 0.4
1.8 Parameterization softwares
—
—
—
—
Configuration with SIMOCODE ES or
SIMATIC PDM
—
—
—
Introduction
